Circulating Bath Chiller for Cooling and Heating

Model

SUNDI-6A25W

SUNDI-6A38W

SUNDI-6A60W

SUNDI-6A95W

SUNDI-6A130W

Temperature range ℃

-60℃~250℃

Controller

Feed forward PID +Our special dynamic control calculation, PLC controller

Communication

MODBUS RTU Protocol, RS 485 Interface

Temp. control

Process temperature control mode

Program Editor

20 programs, each program can edit 45 steps.

Temperature feedback

Heat-conducting medium feedback PT100, (oil outlet temperature,

oil inlet temperature and heater temperature), Three temperature measuring points.

Process Temperature feedback

Raw material process feedback PT100 or 4~20mA input (optional)

Temp. accuracy

±1℃

±1℃

±1℃

±1℃

±1℃

Heating power

25kW

38kW

60kW

95kW

130kW

Cooling capacity

250℃

25kW

38kW

60kW

95kW

130kW

100℃

25kW

38kW

60kW

95kW

130kW

20℃

25kW

38kW

60kW

95kW

130kW

0℃

25kW

38kW

60kW

95kW

130kW

-20℃

25kW

38kW

56kW

80kW

90kW

-40℃

18kW

22kW

30kW

45kW

56kW

-55℃

6kW

7.5kW

11kW

15kW

19kW

Circulation pump

Max110L/min

2.5BAR

Max150L/min

2.5BAR

Max250L/min

2.5BAR

Max250L/min

2.5BAR

Max250L/min

2.5BAR

Compressor

Copeland

Copeland

Copeland

Bock

Bock

Evaporator

KAORI Plate heat exchanger

Oil separator

Emerson

Expansion valve

Emerson

Operation panel

Optional 7-inch color touch screen controller, temperature curve record, data export to excel format.

Safety protection

Self-diagnosis function; freezer overload protection; high pressure switch,

overload relay, thermal protection device, liquid low level protection,

high temperature protection and temperature fault protection.

Closed
circulation system

The whole system is full closed circulation, there is no oil mist at high temperature

and no water vapor at low temperature, pressure do not rise up when system is running.

The system will supplement oil automatically at low temperature.

Refrigerant

R-404A R23 mixed Refrigerant

Connection size

DN25 PN10

DN32 PN10

DN40 PN10

DN40 PN10

DN40 PN10

Water-cooled type W

(cooling water at 30℃)

8.5m³/h

1.5bar~4bar

14m³/h

1.5bar~4bar

20m³/h

1.5bar~4bar

29m³/h

1.5bar~4bar

38m³/h

1.5bar~4bar

water-cooled condenser

Shell and tube exchanger(standard)

Dimension

1500*1000*1750

1800*1200*1750

2050*1450*1750

2300*1450*1750

2750*1600*1850

Weight

980kg

1150kg

1380kg

1750kg

2280kg

Power

AC 380V 50HZ

38kW (max)

AC380V 50HZ

58kW (max)

AC 380V 50HZ

85kW (max)

AC 380V 50HZ

30kW (max)

AC 380V 50HZ

180kW (max)

Case material

SUS 304

SUS 304

SUS 304

SUS 304

SUS 304

Optional

Optional Ethernet interface , configure the computer operating software

Optional

Water condenser use plate heat exchanger (request for high quality water)

Optional power

440V~480V 60HZ three-phase
