Direct-cooled Ultra-low Temperature Freezer
- Shanghai
You May Like
-
With Good Quality Cooling and Heating Thermostatic Applied to Reactor From -100 up to 100 Degree
-
TCU Applied to Glass Reactor Temperature Range From -50 to 250 Degree
-
Air Cooling Chiller of Cooling and Heating Machine Temperature Range From -30 up to 180 Degree
-
Heating Machine of Manufacturer Temperature Range From 50 up to 200 Degree
-
Multifunction Lab Low Temperature Constant Temperature Circulator
-
Refrigerated Thermostatic Bath and Heating Circulators Bath
Product Details
| Type | Other, Ultra-Low Temperature Freezer | Place of Origin | Jiangsu, China | |
| Brand Name | LNEYA | Model Number | SLJ-4 | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Ultra-Low Temperature Freezer SLJ-4 -110°C~-150°C
Description
Medium-sized low-temperature freezer, refrigeration temperature range from -110℃ ~ -150℃, safe, reliable, rapid cooling for the liquid, widely used in petrochemical, medical, pharmaceutical, biochemical and freeze-dried, military and other high-tech industries.
Technical Parameters:
Model | SLJ-3 | SLJ-4 | SLJ-6 | SLJ-11 | |
Temperature range ℃ | -110°C~-150°C | ||||
Cooling capacity | -120°C | 3kW | 4kW | 6kW | 11kW |
-135°C | 2.5kW | 3.3kW | 5kW | 9kW | |
Evaporator space | 2 square meter | 2.8 square meter | 4 square meter | 7.8 square meter | |
Evaporator | Φ16×40m | Φ22*40m | Φ28*45m | Φ28*45m *2 | |
Connection size | Φ16 ball mouth | Φ22 ball mouth | Φ28 ball mouth | Φ35 ball mouth | |
Compressor | Copeland | Copeland | Copeland | Copeland | |
Operating Panel | 7-inch color touch screen controller, temperature curve record, data export to excel format. | ||||
Control system | Standard: Single-chip microcomputer controller; Stepping control; Set temperature difference of refrigeration on & off. Optional: SIEMENS S7-200PLC&Module | ||||
Condenser | KAORI Plate heat exchanger | ||||
Intermediate heat exchanger | KAORI Plate heat exchanger | ||||
Drying filter core | Danfoss | ||||
Expansion tank | Emerson | ||||
FDF | Emerson | ||||
Oil separator | Emerson | ||||
Pressure protector | Emerson | ||||
Reservoir | Standard:RSP Optional:Emerson | ||||
Sight glass | Standard: SANHUA Optional: Danfoss | ||||
Refrigeration ball valve | Standard: SANHUA Optional: Danfoss | ||||
Electric | Schneider AC contactor, Schneider intermediate relay | ||||
Refrigerant | R404A R508B R14 R50 mixed refrigerant | ||||
Safety protection | High pressure protect; Water supply cut-off protection; Over-current protection; Leakage protection; Sequential and phase failure protection; High temperature protection; Sensor Failure protection; Liquid low level protection etc. muti-safety protection. | ||||
Piping material | Copper pipe | ||||
Case material | SUS304 | ||||
HP | 15HP | 20HP | 30HP | 55HP | |
Water-cooled type W (cooling water at 20℃) | 6m³/h | 8m³/h | 12m³/h | 20m³/h | |
Power | 380V50HZ 12kW | 380V50HZ 16kW | 380V50HZ 24kW | 380V50HZ 44kW | |
Connection | 700*750*1700 | 1000*800*1700 | 1250*1000*1750 | 2050*1450*1750 | |
Weight | 700kg | 1100kg | 1400kg | 1800kg | |
dB | Within 75dB | Within 80dB | |||
