SLJ-6W Ultra-low Temperature Freezer From -110 to -150 Degree for Industrial Using
- Shanghai
You May Like
-
CDLJ-120W Freezer Applied to SS Reactor Temperature Range From -115 to -50 Degree
-
CDLJ-45W Low Temp. Freezer Temperature Range From -115 to -50 Degree
-
CDLJ-30W Freezing Machine Temperature Range From -115 to -50 Degree
-
CDLJ-20W Freezing Machine Temperature Range From -115 to -50 Degree Freezer Payment Online
-
CDLJ-15W Freezing Machine Temperature Range From -115 to -50 Degree Freezer Payment Online
-
CDLJ-6W Freezing Unit Temperature Range From -115 to -50 Degree
Product Details
| Place of Origin | Jiangsu, China | Brand Name | LNEYA | |
| Model Number | SLJ-6W | After-sales Service Provided | Overseas third-party support available |
Product Description
Low Temperature Freezer
echnical Parameters:
Model | SLJ-3 | SLJ-4 | SLJ-6 | SLJ-11 | |
Temperature range ℃ | -110°C~-150°C | ||||
Cooling capacity | -120°C | 3kW | 4kW | 6kW | 11kW |
-135°C | 2.5kW | 3.3kW | 5kW | 9kW | |
Evaporator space | 2 | 2.8 | 4 | 7.8 | |
Evaporator | Φ16×40m | Φ22*40m | Φ28*45m | Φ28*45m *2 | |
Connection size | Φ16 ball mouth | Φ22 ball mouth | Φ28 ball mouth | Φ35 ball mouth | |
Compressor | Copeland | Copeland | Copeland | Copeland | |
Operating Panel | 7-inch color touch screen controller, temperature curve record, data export to excel format. | ||||
Control system | Standard: Single-chip microcomputer controller; Stepping control; Set temperature difference of refrigeration on & off. Optional: SIEMENS S7-200PLC&Module | ||||
Condenser | KAORI Plate heat exchanger | ||||
Intermediate heat exchanger | KAORI Plate heat exchanger | ||||
Drying filter core | Danfoss | ||||
Expansion tank | Emerson | ||||
FDF | Emerson | ||||
Oil separator | Emerson | ||||
Pressure protector | Emerson | ||||
Reservoir | Standard:RSP Optional:Emerson | ||||
Sight glass | Standard: SANHUA Optional: Danfoss | ||||
Refrigeration ball valve | Standard: SANHUA Optional: Danfoss | ||||
Electric | Schneider AC contactor, Schneider intermediate relay | ||||
Refrigerant | R404A R508B R14 R50 mixed refrigerant | ||||
Safety protection | High pressure protect; Water supply cut-off protection; Over-current protection; Leakage protection; Sequential and phase failure protection; High temperature protection; Sensor Failure protection; Liquid low level protection etc. muti-safety protection. | ||||
Piping material | Copper pipe | ||||
Case material | SUS304 | ||||
HP | 15HP | 20HP | 30HP | 55HP | |
Water-cooled type W (cooling water at 20℃) | 6m³/h | 8m³/h | 12m³/h | 20m³/h | |
Power | 380V50HZ 12kW | 380V50HZ 16kW | 380V50HZ 24kW | 380V50HZ 44kW | |
Connection | 700*750*1700 | 1000*800*1700 | 1250*1000*1750 | 2050*1450*1750 | |
Weight | 700kg | 1100kg | 1400kg | 1800kg | |
dB | Within 75dB | Within 80dB | |||
