Home > Products > Heating circulator > 50~ 200 Degree Heating Circulators Temperature Control Machine for Industrial Production UC-A6030

50~ 200 Degree Heating Circulators Temperature Control Machine for Industrial Production UC-A6030

FOB Price

US$ 1,000 - 10,000 / Piece

1 Piece(Min. Order)

Port FOB Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	LNEYA		Model Number	UC-A6030
Place of Origin	Jiangsu, China

Product Description

50~ 200 degree Heating circulators temperature control machine UC-A6030

Description:
1. UC series with function of cooling down from high temperature and the temperature range from 300℃ to 50℃.
2. Equipped with heating and cooling system, large heat exchange area, rapid speed of heating-cooling, small demand of heat conducting medium.
3. Can heating-cooling continuously
4. The whole system is closed, there is no oil mist at high temperature, no volatilization of heat conducting medium at high temperature; With function of adjustable internal circulation PT100.
5. The whole system is a closed liquid circulation system with expansion tank, the expansion tank and liquid circulation are thermal insulation, do not participate in liquid circulation, regardless of high or low temperature, the medium in expansion tank is limited to 60℃.

Model		UC-A1530	UC-A2530	UC-A3830	UC-A6030
Temperature range ℃		50℃~300℃
Controller		PID adaptive controller
Temp. Control optional		Heat-conducting medium outlet temp. control
Communication protocol		MODBUS RTU Protocol, RS 485 Interface
Temperature feedback		Heat-conducting medium temperature feedback PT100
Temp. accuracy		±0.5℃	±1℃	±1℃	±1℃
Heating power		15kW	25kW	38kW	60kW Divide to two groups heating
		Heater can be divided into groups. When the testing temperature reached to (setting temperature -5℃), it can close the most of heating duty and leave the next group to be PID fuzzy control.
Cooling capacity	300℃	15kW	25kW	38kW	60kW
	200℃	13kW	22kW	32kW	50kW
	100℃	10kW	17kW	27kW	40kW
	65℃	4kW	6kW	11kW	16kW
		There is a heat exchanger in the system and it needs water to cool. Open the water valve automatically according to demand.
Circulation pump		Max50L/min 2.5BAR	Max110L/min 2.5BAR	Max110L/min 2.5BAR	Max250L/min 2.5BAR
Expansion tank volume		50L	80L	120L	220L
Heater		Orient electric heater
Independent temperature limiter		LNEYA
Cooler		Plate heat exchanger
Operation panel		Display setting temperature and testing temperature; Touch screen display
Safety protection		Self-diagnosis function; freezer overload protection; high pressure switch, overload relay, thermal protection device, liquid low level protection, high temperature protection and temperature fault protection.
Closed circulation system		The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, pressure do not rise up when system is running. The system will supplement oil automatically at low temperature.
Connection size		DN-25	DN-25	DN-25	DN-40
Dimension		6006001250	6006001250	12007501100	12007501100
Weight		115kg	155kg	195kg	320kg
Power		AC380V 50HZ 16kW (max)	AC380V 50HZ 26.5kW (max)	AC380V 50HZ 39.5k (max)	AC380V 50HZ 63kW (max)
Case material		Cold rolled steel painting
Optional		Optional 7-inch color touch screen controller, temperature curve record, data export to excel format.
Optional		SUS 304 SUS 304 case material
Optional power		220V 60HZ three-phase, 440V~480V 60HZ three-phase

Company Information

About Us

Wuxi Guanya Refrigeration Technology Co., Ltd. Specialized in rerfigeration equipment, ultra-low temperature freezer, cooling and heating temperature control system, heating circulation system, explosion-proof electric equipment. Automatic integrated disparate control system, laboratory apparatus. We are the technology leader for high precision thermoregulation solutions in Research and Development Industry. Our products ensure precise temperature control throughout the whole world in laboratories, pilot plants and production processes. Our product range offers temperature control solutions for applications from -152 to +350℃.

We make market and user need oriented products, focusing on science and technology applying international advanced technology, endlessly get rid of the stale and bring forward the fresh following the market step & meet market demand. The company always insists on standardised management in accordance with ISO9001-2008 international quality certification requirement from product design, purchase and selection of components, to production process flow, packaging and transportation etc, try to keep improving products, and keep reasonable price and satisfactory service.

Development history

In 2006 Start production of refrigeration and heating system equipments.

In 2007 Developed the first generation of refrigeration and heating thermostat and establish the LNEYA CO., LTD.

In 2008 Developed the first generation of refrigeration and dynamic temperature control system.

In 2009 Developed the second generation of refrigeration and heating thermostat.

In 2010 Established WUXI GUANYA REFRIGERATION TECHNOLOGY CO., LTD.

Developed the second generation of refrigeration and heating dynamic temperature control system.

Developed the refrigeration and heating dynamic temperature control system & low temperature freezer for industry use.

In 2011 Developed new technology with single compressor having multiple circulation systems (can reach to -80 degree with single compressor)

Upgraded the second generation of refrigeration and heating dynamic temperature control system.

In 2012 Single compressor having multiple circulation systems is applied in production of SUNDI-4, SUNDI-5, SUNDI-6, and SUNDI-7, SUNDI-8 and LT series.

Upgraded the second generation of refrigeration and heating dynamic temperature control system for the second time and developing the third generation of refrigeration and heating dynamic temperature control system.

In 2013 Developed new product one operating multi refrigeration and heating temperature control system(the third generation of refrigeration and heating dynamic temperature control system).At the same time testing the large capacity of ultra-low temperature freezer.

In 2014 Developed with large capacity of ultra-low temperature freezer which used for industrial production,new goods will be research.And it will be launched in the market soon........
