Steel Roof Ridge Cap Roll Forming Machine
- TIANJIN XINGANG
- T/T
You May Like
-
Metal Color Ridge Cap Tile Roll Forming Machine
-
Widely Used Color Steel Metal Roof Ridge Cap Tile Cold Roll Forming Machine
-
High Quality Roller Shutter Roll Forming Machine
-
Good Quality Shutter Door Roll Forming Machine With Competitive Price
-
High Quality Steel Shutter Slat Forming Machine Quality Choice
-
High Quality Aluminum Rolling Shutter Machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Steel | Use | Roof | |
| Production Capacity | 8-12m/min | Place of Origin | Hebei, China | |
| Brand Name | AS | Model Number | 312 | |
| Power(W) | 3+3kw | Voltage | 380V | |
| Dimension(L*W*H) | 6500*1000*1100 | Weight | 4.0T | |
| Certification | CE/ISO9001 | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
What is the parameter of roof ridge cap roll forming machine?
Power supply: 380V, 3 phases, 50 or 60 Hz as user need.
Feeding thickness: 0.3-0.8mm
Feeding width: 500mm
Main power: 3KW
Pump power: 3 kw
Forming speed: 8-12m/min
Roll station: 15 groups
Hydraulic pressure: 10-12Mpa
Cutter material: Cr12
Material of shaft: 45# steel with heat treatment
Diameter of shaft: 75mm
Control system: PLC delta inverter
What is the work flow?
Components of machine:
Decoiler | 1set (3MT capacity) |
Feeding & guiding device | 1set |
Main roll forming machine | 1set |
Hydraulic cutting system | 1set |
Controlling system | 1set |
Run out table | 1set |
Machine pictures
1:Nude in container with plastic film.
2:We can do the packaging according to your need.
Our machines at customers' workshop
1 | One-year quality assurance for all the machine |
2 | Technical staff available to service machine overseas |
3 | Permanent free for technical support |
4 | Design and produce according to your sample or drawing |
We are well recognized manufacturer and supplier of Cold Roll Forming Machine which are supplied to various industries across the nation. Our products are technically advance and designed with the use of latest standard features and functions. These products are highly durable and easy to use. We guarantee superior quality which are duly tested and provided in stipulated time frame.
Customers show
1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.
2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.
3. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi(1 hour), then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
4. How to get a quotation?
a. Give me the profile drawing and thickness, this is the important.
b. Other specific requirements are welcome, such as the speed, power and voltage you want.
5. What can you do if the machine broken?
Our machine's warranty period is 12months! If the broken parts can't repair, we can send the new parts replace the broken parts free,but you need pay the express cost yourself.If after warranty period,we can through negotiation for to solve the problems,and we supply the technical support for the whole life of the equipment.
6. Can you be responsible for transport?
Yes,please tell me the destination port or address.We have rich experience in transport.
