Gas Degassing Beverage Carbonator With High Pressure Mixing Pump for High Gas Drink
- ShangHai Port for drink carbonator
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | Customised | Power | 14.45kw | |
| Place of Origin | Jiangsu, China | Brand Name | YuFeng | |
| Model Number | QHS-9000 | Dimension(L*W*H) | 2810*2010*2450mm | |
| Weight | 1500kg | Certification | CE, ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Gas degassing beverage carbonator with high pressure mixing pump for high gas drink
Main usage:
The beverage carbonator is used for mixing all kinds of carbonated drink with high gas ration.
It mixes the water, sugar, gas together for high quality gas drink, adopts the newest technology.
Technical parameter:
Model | QHS-3000 | QHS-6000 | QHS-9000 | QHS-12000 |
Output | 3T | 6T | 9T | 18T |
Syrup and water adjusting rate | 1:3-1:10 | 1:3-1:10 | 1:3-1:10 | 1:3-1:10 |
Gas mount (CO2:H2O) | 2.5 | 2.5 | 4 | 5 |
Mixing precision | 2% | 2% | 2% | 2% |
Cooling water inlet temperature | 0-4 | 0-4 | 0-4 | 0-4 |
Cooling water inlet pressure | 0.15-0.25Mpa | 0.15-0.25Mpa | 0.15-0.25Mpa | 0.15-0.25Mpa |
Syrup inlet temperature | 2~8 | 2~8 | 2~8 | 2~8 |
Syrup inlet pressure | 0.1~0.2Mpa | 0.1~0.2Mpa | 0.1~0.2Mpa | 0.1~0.2Mpa |
Inlet pressure of carbon dioxide CO2 | 0.7~0.8Mpa | 0.7~0.8Mpa | 0.7~0.8Mpa | 0.7~0.8Mpa |
Purity of carbon dioxide CO2 | 99.9% | 99.9% | 99.9% | 99.9% |
Working pressure of storage tank | 0.45-0.55Mpa | 0.45-0.55Mpa | 0.45-0.55Mpa | 0.45-0.55Mpa |
Motor power | 5.8kw | 6.3kw | 14.5kw | 16kw |
External size (L*W*H) | 2000×1400×2200 | 2100×1500×2270 | 2810×2010×2450 | 3200×2200×2500 |
Weight | 1200kg | 1350kg | 1500kg | 1950kg |
Main photos for ref:
-- 9T/H beverage carbonator
--For mixing sugar + water + gas
--Main material: stainless steel 304
--High gas containing, 4 times gas mixing,
--High quality pressure meters
--Even mixing and accurate proportion
--The production capacity, water, sugar proportion and gas content can be adjusted without exchanging any parts.
--Has a battle heat exchanger to cool the sugarwater mixture and carry out twice carbonating.
independent electronic control box.
--With 5 mixing tank
--With gas degassing function
--With automatic PLC touch screen control system
--With automatic alarm system, and emergency stop knob
--With independent electronic control box, high efficiency and more easier control.
-- Stainless steel 304 connection pipe and valves
--With water chilling function
--With high pressure mixing pump.
--With flowmeter in tanks for better showing.
--With mirrors in small tanks for easy observation.
