80ton 200ton Mobile Hydraulic Telescopic Boom Bucket Truck With Heavy Crane
- Any port in China
You May Like
-
160ton 200ton Mobile Heavy Lorry Crane Truck With Crane
-
Truck Mounted Crane 5ton 10ton 20ton 200ton Truck Crane
-
80ton Mobile Hydraulic Telescopic Boom Truck Crane Sale
-
Power Fire Truck Mini Fire Fighting Truck Foton Fire Trucks
-
Water & Power Fire Fighting Truck Fire Rescue Truck Water Tank Fire Fighting Truck
-
7000L Fire Truck Water Capacity Types of Fire Trucks Fire Fighting Truck for Sale
Product Details
| Condition | New | Application | Workshop, agriculture, industry, transportation | |
| Rated Loading Capacity | 2ton-200ton | Rated Lifting Moment | 3200KN.m | |
| Max. Lifting Load | 200,000kg | Max. Lifting Height | 10m | |
| Span | 6.9m | Place of Origin | Hubei, China | |
| Brand Name | HOWO, CLW | Model Number | CLW160 | |
| Certification | ISO9001 | Warranty | 12months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
No. | Item | Unit | Parameter |
1 | Total mass in travel state | kg | 72000 |
2 | Overall length for travel | mm | 16200 |
3 | Overall width for travel | mm | ≤3000 |
4 | Overall height for travel | mm | ≤4000 |
5 | Chassis length | mm | 14240 |
6 | Max. travel speed | km/h | 71 |
7 | Min. stable travel speed | km/h | 2 |
8 | Drive type |
| 8×4 |
9 | Steering type |
| 8×4 |
10 | Approach angle | ° | ≥25 |
11 | Departure angle | ° | ≥17.8 (24) |
12 | Max. grade-ability | % | ≥55 |
13 | Carrier engine rated output | kw/rpm | 336/380/1800 |
14 | Superstructure engine rated output | kw/rpm | 162/2100 |
15 | Outrigger type |
| Double H |
16 | Outrigger span(longitudinal×lateral ) | mm | 9625×8700 |
17 | Min. turning diameter | mm | ≤23000 |
18 | Max. rated lifting capacity | kg | 200000 |
19 | Jib max. lifting capacity | kg | 12000 |
20 | Min. rated working radius | m | 3 |
21 | Max. load moment | kN .m | 6350(9m×72t) |
22 | Boom elevation | ° | 0~82 |
23 | Boom length | m | 13.8 |
24 | Fully extended boom length | m | 61 |
25 | Base boom lifting height | m | 14.5 |
26 | Fully extended boom lifting height | m | 59.5 |
27 | Jib length | m | 11.55, 20 |
28 | Swing speed | r/min | 0~2 |
29 | Single rope hoist speed | m/min | 0~120 |
