China PP Spunbonded Non Woven Fabric Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Big Roll PP Spunbonded Nonwoven Fabric For Agriculture

Product Description

Product Details
Item	Non-Woven Fabric
Production Line	S,SS,SMS PP spunbonded nonwoven production line
Width	1.6-3.2m
Weight	9-200gsm
Width	2.5-6D
Weight	9-200gsm
Production Capability(T/Y)	3600,7200,1200,5200
Screw Diameter(mm)	130-170
Length-diameter Ratio	30:1
Machine Speed	10-120m/min
Fabric Color	Any color available
Finished Fabric Feature	Waterproof, anti-uv, anti-static, anti-pull, anti-alcohol, anti-oil, eco-friendly
Certification	ISO

Raw Material Specification

Item	Unit	Technical index
Melting Index	g/10min	27~35
Melting Point	°C	162~165
Density	G/cm3	0.90~0.91
Molecular Weight Distribution	MW/Mn	<=4
Content Of Grey	PPM	<=250
No Equal Normality	%	<=3.5
Content Of Water	%	<0.05
Stretch Strength	Mpa	>=31

General Information For Machine

Type	Output	Operating capacity	Power Consumption	Transformers Required	Size of machine (WLH)	Container Required
1.6m S machine	1500 ton/year	130kw	800kw*h/ton	250KVA	9m17m10.5m	5 containers of 40HQ
1.6m SS machine	3000 ton/year	260kw	800kw*h/ton	315KVA	10m25m10.5m	10 containers of 40HQ
2.4m S machine	2200 ton/year	220kw	800kw*h/ton	250KVA	12m17m10.5m	6 containers of 40HQ
2.4m SS machine	4400 ton/year	440kw	800kw*h/ton	630KVA	14m25m10.5m	12 containers of 40HQ
3.2m S machine	3000 ton/year	300kw	800kw*h/ton	315KVA	13m22m10.5m	7 containers of 40HQ
3.2m SS machine	6000 ton/year	600kw	800kw*h/ton	800KVA	17m30m10.5m	14 containers of 40HQ

Parts of Production Line
Screw extruder ---> Rim charge auxiliary screw and recycling device ---> Spinning beam ---> Filter---> Metering pump---> Monomer suction device---> Quenching air chamber---> Stretching device---> Calender---> Tension device---> Winder and suction system.
Spunlaid Process and Technical Flow Chart
Additive(recycling waste edge)---> Raw material -->Melting--> Filtering-->Measuring-->Spinning-->Cooling-->Stretching-->Web forming-->Calendering-->Rounding-->Final products.
Application
Medical: operation suit ,exposure suit,cap,sauna clothes face mask,shopping bag,disposable clothes and so on Agricultural: Cover for plant to anti-forst,insect-resistant sunshades,awning clothes,packing bags for crops,etc Industry: Interior decoration for car,train and ship;back fabric for man-made carpets,etc Packing and Lining: Bags for business,shopping and parents packet,dust cover,sleeping bag for children,leather shoes,luggage,mattress,sofa lining and so on.

Product Show

Flow of PP Nonwoven Fabric Machine

Certificate

Packaging & Shipping

Trade Details
MOQ	2 tons Nonwoven Bag Making Machine
Payment Terms	L/C, T/T
Port	Shanghai
Delivery	10-20days (5-10 days for urgent orders)
Fabric Load Quantity	One 20FT can be loaded about 5-6tons One 40HC can be loaded about 12-16tons
Packaging	Packed in a roll and then in a pe bag
Shipping	By air, by sea, express according to your requirement
