Main Switch FDD16-125 1P
- 300000 Piece / Pieces per Month
- Ningbo Shanghai
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CROP | |
| Model Number | FDD16 series | Max. Current | 125 | |
| Max. Voltage | 230/400V |
Product Description
Main Switch FDD16
Construction and Feature:
1. Capable of switch electriccircuit with load
2. Adaptable to padlock device
3. Contact position indication
4. Capable of quickly releasingstored energy operation
5. High short-circuit currentwithstand capacity
6. Used as main switch forhousehold and similar installation
7. Highlighted of high making and breaking capacity
Technical Data
Pole No.:1,2,3,4
Rated Current:68,80,100,125A
Rated voltage:230/400V AC
Rated frequency:50/60Hz
Rated withstand current:1000A within 1sec
Electro-mechanical endurance:10000 cycles
Connection capacity: Rigid conductor 25mm2
Connection terminal: Screw terminal, pillar terminal withclamp
Installation: On symmertrical din rail 35mm, panel mounting
