Complete full sets zircon ore processing line

Specifications

Complete full sets zircon ore processing line

 Gelin Company Information:

—We have passed ISO9001:2008 Quality System certification.

—Our products have obtained the title of "China High Quality Well-Known Products".

—Our products are sold to more than 28 provinces/cities in China and are exported to Russia, Africa, India,the Middle East, the Philippines, Mongolia, Sudan, Kazakhstan, Brazil, America, Canada and Australia.

 —We have won high reputations from all of our clients for our machines and services.

 Beach heavy mineral sand separating machine electrostatic separator

The Electrical sorting method used the differences of conductive of different mineral, Under the influence of electric field, mineral particles are subject to electrical and mechanical forces(centrifugal force, gravity, drag) role, then they produce different tracks that make them to be separated, so we can achieve the purpose of sorting.

When the temperature heated to 40°C-60°C after entered into the bin. the mineral particles enter into the power corona areas with the rotation roller shafts along the rotating feed roller(Grounding Electrode)surface, Corona current makes all the mineral particles(conductors and non-conductors) obtain negative charge, Because of low contact resistance. with the rotating feed roller, the conductor’s charges transfer by the roller away quickly, Under the action of mechanical forces, conductors escape away from the roller, and enter into the mineral hopper(conductors), At the same time, because of higher contact resistance with the rotating feed roller, the non-conductors’charges couldn’t transfer by the roller away as quickly as conductors’, so they are forced in the roller surface owing to the role of electrostatic force, with the rotating feed roller, the non-conductors enter into the back of the roller, and are unloaded under brush, Then they are collected in the excellent hopper(non-conductors), At last the Semiconductor mineral particles or failed to fully discharge the conductor mineral particles enter into the middle hopper(semiconductor mineral particles).

With the reasonable structure, advanced technology, convenient operation, complete protection, high degree of automation, safety and reliable, with better separating effect.

Separation of high accuracy, can make the 120 mesh mineral to 2 mm.

High degree of automation, to achieve the feeding, heating, speed adjustment, high-pressure discharge, with high security.

Four Roller Electrical Sorter is formed mainly by ore equipment, grounded roller, electrode, corona electrode, deflection electrodes, divided mineral board, high voltage electron genetator and so on.

Specification:

Quantity: Four

Diameter: 120mm-220mm

Length: 1500mm

Speed: 0-500r/min

Corona electrode: The diameter is 0.3mm~0.5mm, and each roller has one.

Deflection electrode: The diameter is 40mm, and each roller has one.

Operating voltage: 0~45kv,and the input is negative.

Particle size of mineral: Not more than 3mm.

Processing ability: 0.5~3 ton/hour.

Transmission power: 1.1~1.5kw, Speed variable motor.

Heating power: Y_4.5kw/_13kw.

Grounding resistance: Less than 10 Ohm.

Material heating method. Manual / Auto.

Host dimensions:

Length: 2090mm

Width: 1020mm

Height: 4500mm

Host weight: 2ton.

Application: Zircon ore, rutile, monazite, ilmenite, tin, gold etc.

Our equipments used in large scale zircon, rutile, ilmenite minerals sand project:

 Producing Machine Products of Our Factory:

  If you also need,pls feel free to contact me ,Thanks !

Our service

♦ Pre-sale services: Passion &thoughtful

 We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

♦ Sale services: Oversea Technicians

Oversea technicians will be sent to the jobsite for guiding the installation training operators and finishing the check and accept together with you.

♦ After-sale services: Faithfulness

One year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

 FAQ

1. Do your machines separate each magnetic iron ore, ilmenite, zircon, rutile, monazite, tin, gold ?, The minerals are not mixed?

 No any problem for our machines to separate the above minerals independence.

As usual, the zircon ore grade is 65-66% after our machine working. You also get iron ore, ilmenite, rutile, monazite, tin, gold each, the minerals not mixed. the grade of minerals reach the international market level for sale.

 2.Why buy from us?

1)Our factory covering an area of over 30,000 square meters

2)Our company having more than 30 sets of heavy processing equipment and with an annual output of more than 2000 sets of mining machinery

3)Our products are sold to more than 28 provinces/cities in China

4)Our products have exported to Russia,Africa,India,the Middle East,the Philippines, Mongolia, Sudan, Kazakhstan, Brazil, America, Canada , Australia and so on

5)Delivery fast -----Goods be sent out within 5 to 20 days based on order quantity

6)Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long-term business

3. What is capacity you want? How many tons per hour?

Please answered aboved questions,so we can suggest you the suitable type.
