DEUTZ Series Diesel Generator Sets
- Fuzhou
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | Pengjie | |
| Model Number | DEUTZ- | Output Type | Other, AC signle phase and AC three phase | |
| Speed | 1500/1800rpm | Frequency | 50Hz/1500rpm;60Hz/1800rpm | |
| Rated Power | 400/230;380/220;etc | Rated Voltage | 20kw-1000kw, 20kw-1000kw as your need | |
| Rated Current | 36A-1800A |
Product Description
DEUTZ Series Diesel Generator Sets
Model | Prime power | Engine model | No.of cyls | Bore/stroke | Fuel Cons. | Dimension | Weight(kg) | |
KW | KVA | (mm) | (L/hr) | (L*W*H) (mm) | ||||
Air-cooled Series | ||||||||
GF2-12D | 12 | 15 | F2L912 | 2 | 100/120 | 4 | 1400*800*1100 | 500 |
GF2-20D | 20 | 25 | F3L912 | 3 | 100/120 | 4 | 1700*800*1100 | 700 |
GF2-24D | 24 | 30 | F4L912 | 4 | 100/120 | 9.7 | 1900*800*1150 | 800 |
GF2-36D | 36 | 45 | F4L912T | 4 | 102/125 | 9.7 | 2000*800*1150 | 950 |
GF2-40D | 40 | 50 | F6L912 | 6 | 100/120 | 14.5 | 2250*800*1150 | 1150 |
GF2-48D | 48 | 60 | F6L912T | 6 | 100/120 | 14.5 | 2250*800*1150 | 1200 |
GF2-64D | 64 | 80 | BF6L913 | 6 | 102/125 | 24.9 | 2400*800*1250 | 1300 |
GF2-76D | 76 | 95 | BF6L913C | 6 | 102/125 | 30.7 | 2500*800*1350 | 1500 |
Water-cooled Series | ||||||||
GF2-20D | 20 | 25 | D226B-3D | 3 | 105/120 | 6.5 | 1620*780*1200 | 780 |
GF2-24D | 24 | 30 | D226B-3D | 3 | 105/120 | 6.5 | 1620*780*1200 | 780 |
GF2-34D | 34 | 42 | TD226B-3D | 3 | 105/120 | 9.6 | 1620*780*1200 | 810 |
GF2-48D | 48 | 60 | TD226B-4D | 4 | 105/120 | 13.6 | 1950*750*1650 | 950 |
GF2-80D | 80 | 100 | TD226B-6D | 6 | 105/120 | 20.8 | 2230*840*1700 | 1210 |
GF2-104D | 104 | 130 | TBD226B-6D | 6 | 105/120 | 26.4 | 2300*840*1740 | 1350 |
GF2-120D | 120 | 150 | TBD226B-6D5 | 6 | 105/120 | 30.3 | 2300*840*1740 | 1450 |
GF2-68D | 68 | 85 | BF4M1013E | 4 | 108/130 | 11.9 | 1920*740*1520 | 1150 |
GF2-80D | 80 | 100 | BF4M1013EC | 4 | 108/130 | 14 | 2056*870*1472 | 1200 |
GF2-104D | 104 | 130 | BF6M1013E | 6 | 108/130 | 17.5 | 2473*900*1546 | 1330 |
GF2-121D | 121 | 151 | BF6M1013EC | 6 | 108/130 | 20.3 | 2473*900*1546 | 1330 |
GF2-150D | 150 | 188 | BF6M1013FC | 6 | 108/130 | 28 | 2595*900*1546 | 1540 |
GF2-165D | 165 | 206 | BF6M1013FC | 6 | 108/130 | 28 | 2595*900*1546 | 1540 |
GF2-190D | 190 | 237.5 | BF6M1015 | 6 | 132/145 | 32.2 | 2453*1040*1822 | 1880 |
GF2-260D | 260 | 325 | BF6M1015C | 6 | 132/145 | 44.1 | 3060*1315*2035 | 2300 |
GF2-280D | 280 | 350 | BF6M1015C2 | 6 | 132/145 | 47.6 | 3060*1515*2035 | 2490 |
GF2-300D | 300 | 375 | BF6M1015CP | 6 | 132/145 | 50.4 | 3060*1515*1095 | 2540 |
GF2-345D | 345 | 431 | BF8M1015C | 8 | 132/145 | 60.4 | 3208*1515*1975 | 2870 |
GF2-380D | 380 | 475 | BF8M1015C2 | 8 | 132/145 | 66.5 | 3208*1515*1975 | 2970 |
GF2-400D | 400 | 500 | BF8M1015CP | 8 | 132/145 | 70.7 | 3200*1815*1978 | 3190 |
Cetificate
Quality Assurance
Factory Inspection, the test items before delivery are mainly as follows:
1. Each genset shall be put into commission more than 4 hours totally.
They are tested on idle load, fully load and 10% overload
2. The noise level is tested
3. All of the meters on the control panel shall be tested
4. The appearance of the genset and all of the label and nameplate shall be checked
Warranty policy
Guarantee for one year or 1200 hours whichever reach first from ex-factory date. During the guarantee period, PENGJIE will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, PENGJIE provides cost spare parts maintenance of alternator.
Service Hotline: +86-593-6373566 /+86 18059305586
Manufacturing Standards
GB755, Third part of BS 5000,VDE 0530, NEMA MG1-22,IEC34,CSA C22.2-100 and ASB59
FAQ:
1.Q: What is your MOQ of this item?
A: 1-10PCS
2.Q: What is the lead time?
A: 15-20 days after receiving your L/C or TT deposit.
3.Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A: Fuzhou, China Port.
5.Q: What are your payment terms?
A: 30% deposit and balance T/T against copy of Bill of Lading or L/C at sight.
6.Q: What is your company's available production capacity?
A: 3000-5000 pieces against your orders.
