Home > Products > Steel Shot > 1010 1015 Low Carbon Steel Shot 1/4 Inch
1010 1015 Low Carbon Steel Shot 1/4 Inch
- qingdao
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | pengcheng | |
| Model Number | steel shot | Material | Other, carbon steel |
Product Description
great service is our mission ,high quality is our obligation
CHARACTER OF PRODUCT
1010 1015 carbon steel shot
size:0.5mm to 25.4mm
meterial:carbon steel ,AISI 1010/1015
grade:G10 to G1000
hardness:55-65hrc
application:Bicycle, bearing, pulley, slide, handcraft, shelf, luggage, hardware, grinding media
| DIMENSION AND WEIGHT CONVERSION CHART | ||||||||
| Size | Nos / kg | Weight of 1000 | Size | Nos / kg | Weight of 1000 | |||
| Inch | mm | balls in kg. | Inch | mm | balls in kg. | |||
| 1.500 | 72124 | 0.015 | 3/4" | 19.05 | 35 | 28.571 | ||
| 1/16" | 1.5875 | 60843 | 0.016 | 25/32" | 19.844 | 31 | 32.258 | |
| 5/64" | 1.9844 | 31500 | 0.032 | 20 | 30.5 | 32.787 | ||
| 2.000 | 30427 | 0.033 | 13/16" | 20.638 | 28 | 35.714 | ||
| 3/32" | 2.381 | 18058 | 0.055 | 21 | 26 | 38.462 | ||
| 2.500 | 15612 | 0.064 | 27/32" | 21.431 | 25 | 40 | ||
| 7/64" | 2.778 | 11478 | 0.087 | 22 | 23 | 43.478 | ||
| 3.000 | 9035 | 0.111 | 7/8" | 22.225 | 22 | 45.455 | ||
| 1/8" | 3.175 | 7622 | 0.131 | 23 | 20 | 50 | ||
| 3.500 | 5689 | 0.176 | 29/32" | 23.019 | 20 | 50 | ||
| 5/32" | 3.969 | 3902 | 0.256 | 15/16" | 23.813 | 18 | 55.556 | |
| 4.000 | 3811 | 0.262 | 24 | 17.64 | 56.689 | |||
| 4.500 | 2677 | 0.374 | 31/32" | 24.606 | 16.37 | 61.087 | ||
| 3/16" | 4.763 | 2258 | 0.443 | 25 | 15.61 | 64.061 | ||
| 5.000 | 1951 | 0.513 | 1" | 25.4 | 14.88 | 67.204 | ||
| 7/32" | 5.556 | 1422 | 0.703 | 26 | 13.88 | 72.046 | ||
| 15/64" | 5.953 | 1155 | 0.866 | 1 - 1/16" | 26.988 | 12.41 | 80.58 | |
| 6.000 | 1129 | 0.886 | 28 | 11.11 | 90.009 | |||
| 1/4" | 6.350 | 953 | 1.049 | 1 - 1/8" | 28.575 | 10.45 | 95.694 | |
| 17/64" | 6.747 | 794 | 1.259 | 30 | 9.03 | 110.742 | ||
| 7.000 | 711 | 1.406 | 1 - 3/16" | 30.163 | 8.89 | 112.486 | ||
| 9/32" | 7.144 | 669 | 1.495 | 1 - 1/4" | 31.75 | 7.62 | 131.234 | |
| 5/16" | 7.938 | 487 | 2.053 | 32 | 7.44 | 134.409 | ||
| 8.000 | 476 | 2.101 | 1 - 5/16" | 33.338 | 6.58 | 151.976 | ||
| 11/32" | 8.731 | 366 | 2.732 | 34 | 6.20 | 161.29 | ||
| 9.000 | 334 | 2.994 | 1 - 3/8" | 34.925 | 5.72 | 174.825 | ||
| 3/8" | 9.525 | 282 | 3.546 | 35 | 5.68 | 176.056 | ||
| 10.000 | 243 | 4.115 | 36 | 5.22 | 191.571 | |||
| 13/32" | 10.319 | 222 | 4.505 | 1 - 7/16" | 36.513 | 5.01 | 199.601 | |
| 11 | 183 | 5.464 | 38 | 4.44 | 225.225 | |||
| 7/16" | 11.113 | 177 | 5.65 | 1 - 1/2" | 38.1 | 4.41 | 226.757 | |
| 29/64" | 11.509 | 160 | 6.25 | 1.9/16" | 39.688 | 3.900 | 256.41 | |
| 15/32" | 11.906 | 144 | 6.944 | 40 | 3.810 | 262.467 | ||
| 12 | 141 | 7.092 | 1.5/8" | 41.275 | 3.470 | 288.184 | ||
| 31/64" | 12.303 | 131 | 7.634 | 1.11/16" | 42.863 | 3.100 | 322.581 | |
| 1/2" | 12.7 | 119 | 8.403 | 1.3/4" | 44.45 | 2.780 | 359.712 | |
| 13 | 111 | 9.072 | 45 | 2.680 | 373.134 | |||
| 17/32" | 13.494 | 99 | 10.101 | 1.13/16" | 46.038 | 2.500 | 400.000 | |
| 14 | 89 | 11.236 | 1.7/8" | 47.625 | 2.260 | 442.478 | ||
| 9/16" | 14.288 | 84 | 11.905 | 1.15/16" | 49.212 | 2.060 | 485.437 | |
| 15 | 72 | 13.889 | 50 | 1.95 | 512.821 | |||
| 19/32" | 15.081 | 71 | 14.085 | 2" | 50.8 | 1.860 | 537.634 | |
| 5/8" | 15.875 | 61 | 16.393 | 2.1/8" | 53.975 | 1.550 | 645.161 | |
| 16 | 60 | 16.667 | 55 | 1.47 | 680.272 | |||
| 21/32" | 16.669 | 53 | 18.868 | 2.1/4" | 57.15 | 1.310 | 763.359 | |
| 17 | 50 | 20 | 60 | 1.13 | 884.956 | |||
| 11/16" | 17.463 | 46 | 21.739 | 2.3/8" | 60.325 | 1.12 | 892.857 | |
| 18 | 42 | 23.809 | 2.1/2" | 63.5 | 0.95 | 1,052.63 | ||
| 23/32" | 18.256 | 40 | 25 | |||||
FICILITIES
A:Ball flashing machine
B:Lapping machine
C:Classification machine
D:Roller heat trating furnaces
E:Steel ball vibrometer
FLOW CHART
PRODUCTS FORM
1. Stainless steel shot, with material AISI304, 316, 420C, 440C
2.Carbon Steel shot, with material AISI 1008-1086.
3. Chrome steel shot,with material: AISI52100
4. Brass balls,Copper balls,with meterial AISI c2700
5.Grinding meadia,with meterial AISI 1008-1015
PACKING
Oily packing in pouch packing,plastic/tin box packing
1, 25kg/carton with steel pallet packing
2,25kg/carton without steel pallet packing
3,10kg/box then in wooden case packing
4,250kg/ steel drum packing
5.according to customers' requirement
CERTIFCATION
CONTACT WAY
