Home > Products > U Bolt & Eye Bolt > Stainless Steel Shoulder Eye Bolt G279
Stainless Steel Shoulder Eye Bolt G279
Negotiable
1 (Min. Order)
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | K-Wing | |
| Material | Stainless steel |
Product Description
Specifications
Stainless Steel Shoulder Eye Bolt G279High Polished Stainless Steel - AISI 316
Stainless Steel Shoulder Eye Bolt G279
High Polished Stainless Steel - AISI 316
| Art No. | Size | G | A | D | D1 | L | L1 | W.L.L |
| (inch) | (inch) | (inch) | (inch) | (inch) | (lbs) | |||
| MR0635-0006 | 1/4"x1" | 1/4"-20 | 0.53 | 0.19 | 0.75 | 2.29 | 1.02 | 650 |
| MR0635-0008 | 5/16"x1-1/8" | 5/16"-18 | 0.59 | 0.25 | 0.88 | 2.74 | 1.15 | 1200 |
| MR0635-0010 | 3/8"x1-1/4" | 3/8"-16 | 0.69 | 0.31 | 1 | 3.07 | 1.27 | 1550 |
| MR0635-0012 | 1/2"x1-1/2" | 1/2"-13 | 0.91 | 0.38 | 1.19 | 3.7 | 1.53 | 2600 |
| MR0635-0014 | 5/8"x1-3/4" | 5/8"-11 | 1.13 | 0.5 | 1.38 | 4.45 | 1.79 | 5200 |
| MR0635-0019 | 3/4"x2" | 3/4"-10 | 1.38 | 0.63 | 1.5 | 5.07 | 2.05 | 7200 |
| MR0635-0022 | 7/8"x2-1/4" | 7/8"-9 | 1.56 | 0.75 | 1.75 | 5.87 | 2.31 | 10600 |
| MR0635-0025 | 1"x2-1/2" | 1"-8 | 1.81 | 0.88 | 2 | 6.66 | 2.57 | 13300 |
| MR0635-0032 | 1-1/4"x3" | 1-1/4"-7 | 2.28 | 1 | 2.5 | 7.95 | 3.09 | 21000 |
| MR0635-0038 | 1-1/2"x3-1/2" | 1-1/2"-6 | 2.75 | 1.25 | 3 | 9.49 | 3.6 | 24000 |
