Jaw Swage Terminal Welded
Negotiable
1 (Min. Order)
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | K-Wing | |
| Application | marine and architectural hardware | Material | Stainless steel | |
| Dimensions | For wire rope 2mm to 12mm |
Product Description
Specifications
Jaw Swage Terminal WeldedMaterial: Stainless Steel AISI316
Jaw Swage Terminal Welded
Material: Stainless Steel AISI316
| Art. No. | Wire | L1 | L2 | H | D | A |
| (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |
| MR0112-0002 | 2 | 55 | 24 | 8 | 5 | 6 |
| MR0112-0025 | 2.5 | 55 | 24 | 10 | 5 | 6.5 |
| MR0112-0003 | 3 | 65 | 32 | 10 | 6 | 7.5 |
| MR0112-0004 | 4 | 77 | 40 | 11 | 8 | 11 |
| MR0112-0005 | 5 | 88 | 57 | 14 | 9 | 12 |
| MR0112-0006 | 6 | 106 | 63 | 20 | 12 | 14 |
| MR0112-0007 | 7 | 116 | 70 | 22 | 12 | 15 |
| MR0112-0008 | 8 | 145 | 85 | 26 | 16 | 17 |
| MR0112-0010 | 10 | 150 | 90 | 30 | 19 | 20 |
| MR0112-0012 | 12 | 195 | 105 | 35 | 19 | 23 |
Product include special OEM manufacturing for Architecture, such as handrail fitting, turnbuckles, glass fitting and wire terminals. Marine hardware productions such as stainless snap shackles, wire terminals, anchors, cleat and special designed marine fitting.
