China manufacturer electrical-plating material Cadmium Sheet

Specifications

Cadmium Sheet Details
Cadmium Sheet

ALB Cadmium sheet / Cadmium plate, which are used specially in spent fuel rack/frame of nuclear power station, and ALB are also able to supply you with the other different sizes of the Cadmium sheets used in the other civil industry, the most biggest sizes for the moment are the 0.50mmx950mmx4000mm and 1mmx400mmx5500mm.

Meanwhile, the ALB Cadmium sheet has already proved to be qualified in some of Chinese nuclear power station, such as China Qinshan Nuclear Power station and Fuqin Nuclear Station, which has been replacing the other counterpart import from Germany, France, etc...And our products have already exporting to Germany, France, India, UK, etc....

ALB are able to supply you with the Cadmium sheet with different grade of Cd: 99.95% min., 99.96% min, 99.99% min.

Typical Application for Cadmium Sheets/Plates:
Nuclear Industry: Spent Fuel Rack/Frame of the Nuclear Power Station.
Industrial: In the electrical-plating and shielding industry, a plating coating steel, atomic reactor control rods, photovoltaic cells, etc…

Available Sizes:
Custom Diameter & Sizes, Random Mill lengths

Available Products (forms):
Sheets, Plates, Flat bars, Coils
Custom shapes are available upon request.

Cadmium Sheet
Chemical Composition:
Cd: 99.95% Min.
Cu+Fe+Zn+Pb+Ag+Mg+Al+Si+Bi+Ca+Sn+As+Ni+Co+Te+Mn:0.05% Max.
Note: Cd can be 99.95% min.; 99.96% min.; 99.99% min.

Cadmium Sheet
Typical Physical Properties:
Atomic Number: 48
Atomic Weight: 112.41
Density (g/cm3): 8.65
Melting Point(°C): 320.90
Boiling Point(°C): 765
Thermal Conductivity(W/cm’K): 0.969 at 298.20 K
Electrical Resistivity(microhm-cm @ 20 C): 6.83
Electronegativity: 1.7 Paulings
Heat of Fusion: 1.46 Cal/gm Mole

Cadmium Sheet
Mechanical Properties:
To be Available upon request from Customer

Cadmium Sheets
International Specification / Production Standards

CD Sheets/Plates: ASTM B440

Note:
ASTM: American Society for Testing and Materials
