Metal Sealed Bearing Steel Tooth Tricone Drill Bit

Specifications

1.TCI Tricone drill bit

1>Soft formation TCI Tricone drill bit

         The soft formation TCI tricone drill bit are used to drill low compressive strength,very soft formations.

This bit maximized to use both  conical and chisel tungsten carbid insters of large diameters and high projection.

This cutting structure design combined with maximum cone offset ,result in high bit  penetration rates ,The deep i

ntermesh of cutter rows prevents bit bailing in sticky formations.kingdream drill bit

2>Medium hard formation TCI trcone drill  bit

        The meduim formation TCI tricone drill  bit features aggresive chisel tungsten carbid insters on the heel rows

and inner rows .This design provides a fast drilling rate and added cuttering structure durability in medium and

medium hard formations.The rubber O-ring provide adequate sealing for bearing durability.   kingdream drill bit tricone rock drill bit

  kingdream drill bit

  3>Hard formation TCI tricone drill bit

       The har formation TCI tricone drill bits can be used to drill hard and abbredive formations.Wear resistence

tungsten carbid insters are used in the outer rows to prevent loss bit gauge.Maximm numbers of hemispherical

shaped insterts are used in all rows to provide cutter durability and long life. tricone rock drill bit

Recommended operating parameters

WOB 90 ~ 280(KN)

Ideal WOB range 150~220(KN)

Rotary speed 80 ~ 300 (rpm)

Ideal Rotary speed range 110~250(rpm)

.........................................................................................................................................

Products Details

........................................................................................................................................................................................

Tricone drill bit Advantage:

1.High-strength, high flexibility, high temperature and high wear resistance.

2. High-precision metal seal. rock tricone bit

3. Locking roller ball, to adapt to high-speed.
4. The use of high strength high toughness carbide teeth,  5. Hours in the rotary cone bit with the impact, crushing and shearing the role of broken rock.

6. Cone bit to adapt to the soft, medium and hard of various strata.

7. Reasonable price and long working life.

.............................................................................................................................................................................................

TCI Tricone bit Application For

..............................................................................................................................................................................................

Application:

Rock drill bit is adapt to range from 20 to 150 Mpa.

Tricone drill is now widely used in oil well, water well,mining,geothermal, environmental,

construction,exploration and blast hole.

tricone drill bit

How to complete the whole deal

Step: tricone drill bit

1. Firstly decide the design, material and color  tricone drill bit

2. Decide the size in accordance with client's requirement and our recommendation  tricone drill bit

3. We will give the best offer.  tricone drill bit

4. Client's accept the offer and we send proforma invoice.

5. Client transfers 30%-50% deposit and production begins

6. After production, we will send ready products photo  tricone drill bit

7. After client's confirmation, we will arrange shipment, and send copy shipping documents like B/L,

    commercial invoice and packing list  tric tricone drill bit one drill bit

8. Client transfer balance payment and we will send original documents by express or Telex Release
