Home > Products > energy recovery ventilator > Wheel Construction 380V/3ph/50Hz 3A Plate Heat Exchanger
Wheel Construction 380V/3ph/50Hz 3A Plate Heat Exchanger
Negotiable
/ Unit
1 Unit(Min. Order)
- Any port in CHINA
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | TKM | |
| Structure | Other, Tube Heat Exchanger, rotor, casing, motor etc | Liquid Flow Rate | 1.5-5.5m/s | |
| Maximum Working Pressure | 500Pa | Certification | CE |
Product Description
Specifications
1 Dehumidifier wheel exchanger2.Made of aluminum foils coated with 3A molecular sieve moisture 3.CE certified
Features:
1, Rotary heat exchanger use the most advanced molecular sieve coating technology, enthalpy recovery efficiency in the standard conditions can be guarantee more than 80%.
2, Inserted stiffener reinforce the rotor.
3, Special sealing system lower cross contamination between air streams.
4, Segmented construction easy the long shipping and re-assembly.
5, Selective construstions meet the requirement at jobsit.
Wheel Construction:
The wheel of The rotary heat ex
Various height of corrugation is available.
Flat surface ensures minimum leakage.
