Computerized Narrow Fabric Jacquard needle Loom (JX-JNFS 4/66-640S)-muller loom
- Ningbo or Shanghai
- T/T
You May Like
Product Details
| Condition | New | Type | Jacquard Loom | |
| Place of Origin | Zhejiang, China | Brand Name | Jinxin | |
| Model Number | JX-JNFS 4/66-640S |
Product Description
1)Main characters:
1.With JXGS series of computerized double lift jacquard control system. It is easy to make design and operate.
2.With advanced Jinxin CAD writing system, easy to learn and operate. Compatible with various jacquard CAD
software format, like JC5,EP,UPT, DAT and so on.
3.The memory of jacquard system is 10,000 wefts.
4.Easy to change designs, machine can load data from USB flash disk.
5.High speed designing with free adjusting speed setting. Make it easy to operate in more stable and safety
condition.
2)Special equipment:
HD: Elastic fabric double weft system, weaving rubber thread, auto rubber feeding
JNF-T: Double crochet hook
3) Technical Parameter:
Machine Model | 8/27 | 6/42 | 4/66 |
No. Of Spaces | 8 | 6 | 4 |
Max Reed Width | 27mm | 42mm | 66mm |
Max Tape Width | 25mm | 40mm | 62mm |
Shedding Motion | 12 | 12 | 12 |
Repeat | 1:8/16-32 | 1:8/16-32 | 1:8/16-32 |
No. Of Needles | 128-192 | 192-320 | 192-384 |
Machine Width | 980mm | 980mm | 980mm |
Max Machine Height | 2600mm | 2600mm | 2600mm |
Min Machine Height | 3000mm | 3000mm | 3000mm |
Net Weight | 890kg | 890kg | 890kg |
4)product
