Computerized Jacquard Loom (JX 6/50)
- Ningbo port
- T/T
You May Like
-
Computerized Narrow Fabric Jacquard Loom(JX-JNFS 4/66-640S)
-
Computerized Narrow Fabric Jacquard Machine (JX-JNFS4/66-320S)
-
Computerized Narrow Fabric Jacquard Needle Loom (JX-JNFS6/42-192S)
-
High Speed Non Shuttle Narrow Fabric Needle Loom (JX-NF6/42)
-
Computerized Narrow Fabric Jacquard Needle Loom (JX-JNFS 6/50-320S)
-
(JX-NF8/27S)Super High Speed Narrow Fabric Needle Loom
Product Details
| Condition | New | Type | Jacquard Loom | |
| Place of Origin | Zhejiang, China | Brand Name | JinXin | |
| Model Number | JX 6/50 | Certification | CE |
Product Description
Specifications
Auto lubrication deviceBe applicable to produce all kinds of elastic and unelastic belt and tapes such
as shoelace, ribbon
Detailed Product Description
Apply to produce various kinds of elastic tape and non-elastic tape in cloths. Like elastic fabric , breast tape and etc
Main characters:
1.With JXGS series of computerized double lift jacquard control system. It is easy to make design and operate.
2.With advanced Jinxin CAD writing system, easy to learn and operate. Compatible with various jacquard CAD
software format, like JC5,EP,UPT, DAT and so on.
3.The memory of jacquard system is 10,000 wefts.
4.Easy to change designs, machine can load data from USB flash disk.
5.High speed designing with free adjusting speed setting. Make it easy to operate in more stable and safety
condition.
Special features
TX elasticity weaving double wefts system with latex feeding automatically
JNF-T double hook needles construction
Main technique
Machine model | 8/35 | 6/50 | 4/65 |
number of needles | 128-640 stitch | 128-640 stitch | 128-640 stitch |
Number of ribbons | 8 | 6 | 4 |
Max steel gripper | 35 | 50 | 65 |
Max width | 35 | 50 | 65 |
number of iron frame | 8 | 8 | 8 |
circulation | 1:8/16-32 | 1:8/16-32 | 1:8/16-32 |
rotate speed of the machine | 800-950 r/min | 800-950 r/min | 800-900 r/min |
width of worktable | 980mm | 980mm | 980mm |
max height of machine | 2600mm | 2600mm | 2600mm |
min height of installation space | 1000mm | 1000mm | 1000mm |
weight | 890kg | 890kg | 890kg |
