DC brushless dry run protection fountain pump (BP320607D)
- Ningbo or Shanghai
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Solarever | |
| Model Number | BP320607D | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Nonstandard | |
| Fuel | Other, Electric | Pressure | Low Pressure | |
| Application | Submersible |
Product Description
•Typical applications include creating small fountains, pumping water for water features, circulating and aerating water for aquarium, as well as conducting garden irrigation.
•Brushless motor with no failure-prone carbon brush or shaft seal so that a robust and long service life could be expected.
•DC brushless dry run protection fountain pump could be powered by our solar panel or a DC power supply.
•Self-invented unique dry run protection technique prevents the pump from burning out when fountain or pool dries out.
•Locked rotor protection prevents the pump from possible failure when pump is blocked by pond debris.
•Ceramic shaft, runs steadily and quietly.
•Rohs and CE certified, safe and green.
•IP68 waterproof rating thanks to brushless motor technology.
•Designed and manufactured to have high power efficiency.
•Cost-effectiveness, competitive price.
Item No. | BP320607D | ||||||||
Description | DC brushless dry run protection water pump | ||||||||
Category | DC water pump | ||||||||
| |||||||||
Product Summary | |||||||||
Operating voltage range | DC 6V-9V | ||||||||
Maximum pump head | 0.7m@6V; 1.2m@9V | ||||||||
Maximum flow rate (Litres per hr) | 240L/H@6V; 330L/H@9V | ||||||||
Delivery side (discharge) | 10mm | ||||||||
Flow adjustable | yes | ||||||||
Dry run protection | yes | ||||||||
Removable foam filter | no | ||||||||
Salt or fresh water use | yes | ||||||||
Optional fountain nozzle item | NA01 | ||||||||
Connection cable length | 5m(16.4FT) | ||||||||
Dimensions L, W, H | 73X49X40mm | ||||||||
Warranty | 3 years | ||||||||
| |||||||||
Litres per hour - At various pumping heights (head) | |||||||||
Operating | @ 0m | @0.5m | @0.75m | @1.0m | @1.5m | @2.0m | @2.5m | @3.0m | Max height |
6V | 240 | 174 | 0 |
|
|
|
|
| 0.7m |
9V | 330 | 197 | 126 | 46 | 0 |
|
|
| 1.2m |
| |||||||||
Pump Curve | |||||||||
| |||||||||
