ore thickener concentrator

Ore thickener concentrator

Brief Information:

NZ (S) type (also called TNZ type) thickener is a center drive thickener, which is a concentrate and clarifying equipment with continuous working.

It’s mainly used for dehydrating of concentrate and tailing pulp in wet beneficiation, as well as the industries like coal, chemical, building materials and water sewage treatment etc., Which need solid-slurry concentrated and purified.The product with diameter less than 12mm adopts manual handle, while the diameter with more than 12mm adopts electric handle device.The product has simple structure, low abrasion and convenient maintenance. Large-scale thickener is usually arranged with a concrete tank, with overload indicating or alarming devices.This machine has the features like simple structure, low abrasion and convenient maintenance.

Remarks:

1. For corrosive slurry, an anticorrosive thickener is available, which requires special order.
2. Considering the conditions of transport and construction period, the customer shall specify whether a thickening tan is required or not.

Center driving thickener performance characteristics:

1,Adopt the reducer and the worm gear transmission,High transmission torque,high efficiency,and is provided with a torque protection device,convenient to use;

2,When The load is too large,the scrape mud system underwater can be lifted manually (or electric),then gradually decreased,scraping sludge by layer;

3,The setting mud with a small scraper mixing and scraping mud,discharging mud completely, no blockage.Center driving thickener is mainly consist of concentration tank,frame,transmission device,lifting device,feeding device,discharge device and signal safety device.
