5 Gallon Barrelled Mineral Water Filling Machine / Line
- SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Perfect 5 Gallon / 5gallon Mineral / Water Bottle / Water Filling Machine
-
Automatic 5 Litre Water Filling Packing Machine
-
Perfect 5 Gallon Pure / Purified / Distilled Water Filling Machine
-
Perfect 20l Bottle / Water Filling Machine / Line
-
Perfect Barreled Water Filling Machine / Line / Unit
-
Perfect 5 Gallon Bottle / Bottled / Jar Water Filling Machine
Product Details
| Condition | New | Application | Food, Beverage, Chemical | |
| Packaging Type | Cans, Bottles, Barrel | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | By order | Power | By order | |
| Place of Origin | Jiangsu, China | Brand Name | KM | |
| Model Number | GYB | Dimension(L*W*H) | By order | |
| Weight | By order | Certification | CE,SGS ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
5 Gallon Barrelled Mineral Water Filling Machine / Line1.Used for 3~5 gallon Barrel
2.Application for :Water
3.CE ISO
5 Gallon Barrelled Mineral Water Filling Machine / Line
1.Used for 3~5 gallon Barrel
2.Application for :Water
3.PLC control
4.CE ISO cert.
Introduction:
This filling line specially for 3-5gallons barreled drink water,with type QGF-100,QGF-240,QGF-300,QGF-450,QGF-600,QGF-900,QGF-1200,It intergrates bottle washing,filling and capping into one unit ,In order to achieve the purpose of washing and sterilizing ,The washing machine use multi-washing liquid spray and-thimerosal spray,This thimerosal can be used circularly,The capping machine can cap barrel automatically ,this line equips with water spraying device in order to ensure those caps sterilizer and clean .it also can automatically carry out barrel ,washing,sterilizing ,filling ,capping ,counting and products discharging ,with complete function ,modern design and high degree of automation ,it is a new kind of barreeled water auto-production line ,which intergrates mechanism ,electricity and pneumatics technologies together .
Main technical specifications:
Model | QGF-100 | QGF-300 | QGF-450 | QGF-600 | QGF-900 |
Filling heads | 1 | 2 | 3 | 4 | 6 |
Volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
Capacity(b/h) | 100 | 300 | 450 | 600 | 900 |
Gas consumption (m3/min) | 0.37 | 0.6 | 0.8 | 1 | 1.5 |
Moto power (kw) | 1.38 | 3.8 | 5.6 | 7.5 | 9.75 |
Weight(kg) | 680 | 1500 | 2100 | 3000 | 3500 |
Size(W*L*H)(m) | 0.5*4.0*1.5 | 0.9*4.0*1.5 | 1.3*4.0*1.5 | 1.8*4.0*1.5 | 2.4*4.0*1.5 |
Flow chart :
