Home > Products > casting grinding ball > low Chromium steel Ball
low Chromium steel Ball
- qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Oriental, DT | |
| Model Number | Dia20-150mm, 20MM-150MM | Application | various mines, cement plants, power stations, chemical industries | |
| Material | Steel | Dimensions | Dia20-150mm |
Product Description
Specifications
low Chromium steel Ball1.Hardness:HRC55-67
2.Impact toughness: >12J/CM2
3.Diameter:20-150mm
4.packing:1000kgs bags
Low Chrome Cast Steel Ball
1.Diamater:
Ø20mm-150mm
2.Hardness:
HRC55-HRC67
3.Heat treatment:
Oil quenching & air quenching
4.Main process:
Raw material→Melting by electricstove→Pouring→Polishing→Heattreament→Testing
→Qualified Products→Packing
5.Application:
cenment plant,mines,power station,chemical industry
6.Chemical Composition:
low chrome grinding ball HRC:>46
Medium chrome grinding ball HRC:56-62
High chrome grinding ball HRC:58-65
7.Breakage rate:less than 1%
Type | C | Si | Mn | P | S | Cr | HRC |
High Cr | 2.5-3.2 | 1.0Max | 0.5-2.0 | 0.10Max | 0.06Max | 10-17 | 58min |
Medium Cr | 2.1-3.2 | 0.5-2.2 | 0.5-2.0 | 0.10Max | 0.06Max | 6-10 | 58min |
Low Cr | 2.2-3.6 | 1.2Max | 0.5-2.0 | 0.10Max | 0.06Max | 1.0-3.0 | 58min |
WE LOOK FORWARD TO THE OPPORTUNITY TO DISCUSS HOW WE CAN BECOME YOUR SUPPLY OF CHAIN SOLUTION.
