HOWO Fuel/oil Tank Truck

FOB Price

US$ 40,000 - 50,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.European design style
2.Simple and graceful appearence
3.High strength lightweight
4.Good after-sale service

Name vehicles	HOWO Fuel Tank Truck	Vehicle models	ZZ1257S4647C
Engine Model	WD615.93	Engine power (ps)	290
Engine capacity	9726	Engine manufacturers	SINOTRUK
Dimensions (L×W×H)	1035024963048, 3633	Carriage inner dimension (L×W×H)	76502326600,800
The total mass (Kg)	25000	In the quality of the utilization factor	1.20/1.17
Kerb weight	11360/11480	Rated contained mass (kg)	13510/13390
Trailer total mass	24000	Front overhang	1500/2900
Approach / Rear angle	1612	Rear overhang	2875
Wheelbase	4600+1350,4575+1400	Axle-load	7000/18000
Quantity of Shafts	3	Maximum speed	90,102
Tank capacity	20.4m3	Media	Gasoline
Others	High quality carbon steel plate tanks, shock waves diaphragm tank, Installation of special oil tanker pump

Much more information

Driving Type	6*4
Tank loading capacity(L)	10000L+10000L+3000L
Tank	One set of pump and pipes,one flowmeter
Kerb weight (kg)	9700
Chassis	STEYR chassis
Transmission	FULLER-8, 8 forward & 1 reverse
Max. Speed (km/h)	90
Max. Gradeability(%)	45
Max. Gradeability(%)	45
Overall DimensionL×W×H(mm)	10100x2496x2958, 3563
Brake type	Service braking;dual circuit compressed air brake;parking brake(hand brake);spring energy air cut brake
Wheel Base (mm)	4550+1350
Track Width(F/R)(mm)	1939/1800
Steering	ZF 8098, hydraulic steering with power assistance
Engine Max. Output (kW/rpm)	196 /2200(266HP)
Engine Max. Torque( N.m/r/min)	1100/1300-1600
Front Axle	6.5 ton axle
Rear Axle	2 X STEYR 16Ton axle, central single reduction with hub reduction and with differential locks Ratio:4.42
Cabin	S07 standard cab
Rear Suspension	Leaf springs
Fuel Consumption( L/ 100km)	30
Tire Specification	11.00-20
Fuel Tank (L)	300
Chassis	Strengthened, Cross-Section:300
Chassis	x80x8 mm
Clutch	Φ 420 Single-plate dry,spiral spring clutch
Electric system	electric system,24V,negative grounded
Engine Model	WD615.62, Euro2 emission standard
	Diesel:4-stroke direct injection diesel engine
	6-cylinder in-line with water cooling,turbo-charging and intercooling
	Single cylinder air compressor
