HOWO 8X4 CARGO TRUCK

Specifications

HOWO 8X4 CARGO TRUCK

Engine:WD615.62,EuroII,EuroIII
Clutch:GF430
Transmission:8JS100B,ZF8098steering
Wheels 8.5-20,Tyres 12.00-20
Size:6065*2300*

Howo Cargo truck:

 Features:
1) Engine model: WD615.62, EuroII or EuroIII emission standard
2) Clutch: single-plate dry clutch, GF430, hydraulically operating with air assistance
3) Transmission: 8JS100B,synchromesh,6 forward and 1 reverse
4) Front axle: steering with double T-cross section beam
5) Steering: ZF8098, hydrostatic steering with power assisted, ratio22.2- 26.2

6) Disc wheels 8.5-20
7) Tyres 12.00-20 tube, Option: 12R20 tube,12.00-24 tube,12R22.5 tubeless
8) Maximum driving speed: 102km/h
9) Maximum gradeability: 39%
10) Minimum ground clearance: 298mm
11) Minimum turning circle: 18.6m
12) Fuel consumption: 26L/100km
13) Permissible loading capacity: 8010kg
14) Dead weight: 7860kg
15) Gross vehicle weight: 16000kg
16) Front axle loading capacity: 7,000kg
17) Rear axle loading capacity: 13,000kg
18) Wheel base: 4600mm
19) Front wheel track: 2022/2041mm
20) Rear wheel track: 1,850mm
21) Front overhang: 1,500mm
22) Rear overhang: 2277mm
23) Approach angle: 23degrees
24) Departure angle: 15 degrees
25) Overall length: 8377mm
26) Overall width: 2496mm
27) Overall height: 3048mm
28) Cargo body dimensions:6065 x 2300 x 600mm
