Metal Pipe Laser Cutting Machine for Large Scale Silicon Steel

Specifications

 Metal Pipe Laser Cutting Machine

YAG Metal Tube Laser Cutting Machine

Fast Cutting Speed ,Low operating cost
Mechanical Feature:

The metal pipe laser cutting machine, which is researched and developed by our company,can able to cut and process round and square pipe.

Function:

1.Can cut lines and holes with different diameters from different directions on the pipe, and meet centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.

2.Can cut column Crossed Lines at the end of branch pipe, and meet  centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.

3.Can cut inclined section at the end section of the pipe.

4.Can cut branch pipe intersected with the main circular pipe.

5.Can cut variable angle bevel surface

6.Can cut square hole,waist-shaped hole and circular hole on the pipe.

7.Can truncate the pipe.
8.Can cut all kinds of graphics on the surface of the square pipe.

Application:The machine has been widely used in petroleum exploration, lamps, metal processing, hardware and other industries

Applicable materials:Stainless steel, carbon steel, mild steel, alloy steel, copper, brass, aluminium sheet, titanium sheet and pipe, especially good at processing various high hard and brittle alloy materials.

Equipment Feature and Technical Advantages

1.  Tianqi patented Auto-tracking system

As the pioneer of solid metal laser cutting machine in China, Tianqi Laser machine combined the feature of millions import CO2 laser cutting machine, and developed a fully automated tracking system. It can automatically adjust the best focal length, cut the entire board to ensure the best results, avoid material discarded when the material is not flat and the focal length change. Also the system has the anti-collision function, once hit the cutting down material, the laser will automatically fall to prevent the laser head damaged. The automatic tracking system has been applied for national patents.

2. Transmission System:

Tianqi laser machine uses Taiwan imported high precision ball screw and original imported linear guide, also it uses imported servo motor drive system to effective guarantee the accuracy of laser cutting.

3, Control system
The machine use professional Industrial PC operation, graphical interface, easy operation, professional cutting control software. It can be free to design all kinds of graphics, text, real-time processing, supporting CAD, CorelDraw, and other professional graphics software.

4. Other Advantages

It uses full sealed structure In the optical system, with optical preview and focus indicator function, beautiful appearance and easy operation; the machine is equipped with the latest external water cooling system, low noise operation, high precision control of temperature to ensure a long time reliable operation.

Technical parameter:
