flat head aluminium hollow rivets

Inside packing:10,000pcs in plastic bags, or vacuum plastic bags
Outside packing :5-10 bags in 20cm*20cm*20cm Carton
Max weight in each carton is 20kg

Flat head aluminium hollow rivets

Types of blind rivets have non-locking mandrels and are sometimes avoided for critical structural joints because the mandrels may fall out, due to vibration or other reasons, leaving a hollow rivet that has a lower load-carrying capability than solid rivets.

Blind rivets, commonly are tubular and are supplied with a mandrel through the center. The rivet assembly is inserted into a hole drilled through the parts to be joined and a specially designed tool is used to draw the mandrel into the rivet. This expands the blind end of the rivet and then the mandrel snaps off.

Furthermore, because of the mandrel they are more prone to failure from corrosion and vibration. Unlike solid rivets, blind rivets can be inserted and fully installed in a joint from only one side of a part or structure, "blind" to the opposite side.

 Testing of blind rivets

A blind rivet has strength properties that can be measured in terms of shear and tensile strength. Occasionally rivets also undergo performance testing for other critical features, such as pushout force, break load and salt spray resistance. A standardized destructive test according to the Inch Fastener Standards is widely accepted

The shear test involves installing a rivet into two plates at specified hardness and thickness and measuring the force necessary to shear the plates. The tensile test is basically the same, except that it measures the pullout strength. Per the IFI-135 standard, all blind rivets produced must meet this standard. These tests determine the strength of the rivet, and not the strength of the assembly. To determine the strength of the assembly a user must consult an engineering guide or the Machinery's Handbook

 How to place an order?

About shipment

1. By sea, by air, by door to door express (FedEx, UPS, DHL, TNT, EMS).
2. For Air Shipment, Please choose your favorite, shipping method according your detail requirement
3. The shipping discount is different because of different weight and destination, we will choose the cheapest and safest way according to your detailed requirement.
4. Normally, it will take around 3-7days from China to destination country

Our Advantages

1. Guaranteed quality

INT always promise to provide 100% quality products accord with ISO standard, ROHS/SGS test report, material certificate are available.

Should be any of our products out of quality standard, we will take back the rejects and absorb all the losses occurred.



2. Competitive price

We fixed on the principle of small profit and take full consideration of customer’s cost saving.



3. Prompt delivery

7 days of sample making, 3 days of shipping, to make sure our customer receive cargos at the soonest time.



4. Best service

Whenever you need us, we are available. Whenever you send questions or problems, we'll reply and make solutions within 24 hours.



Thank you for coming to our website. If you have any questions or suggestions, please do not hesitate to contact us, we will reply you within 12 hours, see more products of hollow rivets pls click http://intcn.en.china.cn/productgrouplist-800403121/Hollow_rivets.html !!!
