Full Checked Electrical Agcu Bimetal Strip

Inner packing :5-20kg per coil packing with vacuum plastic film,
Outside packing: 10-20kg in 50cm*50cm*20cm Carton or 30-50kg in 60cm*60cm*30cm wooden box

electrical agcu bimetal strip

 Characteristic:

1. Offer flexibility of material design; being able to produce the electrical contact with high mechanical and electrical contact characteristics

2. Save silver/ precious materials with low prices, as precious metal is only used at electrical contact spots.

 3. Precious Clad Metal Material is suitable for continuous automatically manufacture. It does not need other manufacture process, such as welding or soldering after its formation.

4. It simplifies manufacturing process of electrical parts with high productivity, and raises the assembly precision credibility of electrical component.

 5. Offer flexibility of material design; being able to produce the electrical contact with high mechanical and electrical contact characteristics

 Product Types:

one layer, two layers, three layers,... Inlay

one layer, two layers, three layers...  Onlay/toplay

Overlay /coverlay, edgelay,side day

clad metal strips                 inlay clad metal strips                 overlay clad metal strips               copper clad silver strips

Main Materials:

1.Face material : Ag, AgNi, AgCdO,AgSnO2,AgZnO, AgSnO2In2O3

2.Base material: Cu,brass,Fe, SUS,BeCu,Phosphor copper

Process flow chart

 Specification for silver clad copper strips

All dimensions are according to customers requirements.

Products  Pictures Show:

Equipment & Test Equipment:

Germany Hi-precision Roller Machine; Hi-precision Vertical Cutting Machine; Slotting Machine; Ionic Absorption Test System AAS; Light Processor & Metallographic Microscope; Digital Light Processor; Strength Tester; Hardness Tester.
