Low price new cement silo Concrete Batching Plant Concrete Machinery

Cement silo is a concrete batching plant of supporting products, mainly has the following characteristics:
1.Put in bulk power(cemnent or fly ash)watrerproof and moisture ,easy to use and redure costs.
2.the top of cement silo with green filter, used to reduce dust leakage. Equipped with a safety valve at the top of cement silo, cement silo used to balance the pressure difference between inside and outside. Upper and lower parts of the cement silo is equipped with display materials, can monitor the number of cement materials warehouse. With gas in the lower part of broken cement storage devices, to ensure smooth unloading.
3. Cement bin is cylinder and supporting structure. The superior part has dust removing device to avoid leakage of dust; and the inferior part is equipped with arch breaker to avoid powder caking and make discharging smooth, and bin level sensing device to master usage of material in the bin at any time.
4 Cement bin generally adopts bulk cement conveying truck to send powder in the bin by pneumatic conveying; according different structures of cement bin, there are two kinds of discharging: the first is the inferior part is connected with screw conveyer and screw conveyer send powders into powder measure; the second is to adopt pneumatic conveying (to special cement bin).
Technical index (just for reference)
Serial number Spec Diameter mm Leg height mm Total height mm Theoretical capacity t
1 SNC60          2,800        4,000 (6,000)              8,130                          60
2 SNC100        2,800        4,000 (6,000)              12,000                      100
3 SNC150        3,900       4,000 (6,000)              12,736                       150
4 SNC200        4,500       4,000 (6,000)             13,000                       200
5 SNC500        7,000       4,000 (6,000)            17,500                          500






Sizes above can be changed according to the fact, also can be made according to clients different requirements.
Arch breaker electromagnetic valve AC220v or air control box Level detector LEF-1 (AC220v1A)
Vibrating motor: JZ-0.8(AC380 0.3Kw 0.8KN)
