High pure ceramic fiber blanket with heat insualtion

Specifications

Aluminum silicate ceramic fiber blanket,refractory ceramic fiber blanket  is manufactured from aluminum silicate fiber bulk spinning from kaolinite, alumina silicon dioxide and zircon sand, which been series processing of needling ,cutting and rollings, including 1260°C Standard, 1260°C High pure, 1360°C High Aluminum, 1430°C Zirconium ceramic fiber blanket.

The ceramic fiber blanket with the advantage of uniform quality, smoothly surface ,pure white color, completely inorganic ,good tensile strength, toughness and fiber structure, so there are no flames when heating for the first time , The working temperature ranges from 950°C to 1430 °C.

Product Features

**Low thermal conductivity, low thermal capacit

**Excellent thermal stability and good resistance to heat shock

**Excellent tensile strength

**Good anti-stripping performance

**Good Sound-absorbing performance

**Non-brittleness material, good flexibility

**Excellent machining performance

**Resistance to wind and erosion, long service life

**Excellent heat insulation, fire prevention, sound absorption performance

Specification ofCeramic fiber blanket:

Thicknesses: 10mm, 20mm, 25mm, 30mm, 40mm, 50mm.

Widths: 600mm, 610mm, 1220mm.

Length: 14640mm, 7660mm, 7200mm, 3600mm.

Density: 64 kg/m³, 96 kg/m³,128 kg/m³, 160kg/m³.

The physical properties of ceramic fiber blanket as below :

• Item		Standard	High Pure	High Aluminum	Alu-Zirconium	Zirconium
  Classification Temp (°C)		1260	1260	1360	1360	1430
  Working Temp (°C)		≤1050	≤1100	≤1200	≤1200	≤1350
  Color		Pure White	Pure White	Pure White	Pure White	Pure White
  Bulk Density (Kg/m3)		64-160	64-160	96-160	96-160	96-160
  Permanent Linear Shrinkage(%)		1000°CX24h≤3	1100°CX24h≤3	1200°CX24h≤3		1350°CX24h≤ 3
  Thermal Conductivity (w/m.k)(128Kg/m3)		0.09(400°C) 0.16(800°C)	0.09(400°C) 0.16(800°C)	0.12(600°C) 0.20(1000°C)	0.12(600°C) 0.20(1000°C)	0.16(800°C) 0.20(1000°C)
  Tensile Strength (Mpa)(128Kg/m3)		0.08-0.12	0.08-0.12	0.08-0.12	0.08-0.12	0.08-0.12
  Chemical Composition(%)	AL2O3	45-46	47-49	52-55	45-46	39-40
  	AL2O3+SIO2	97	99	99	-	-
  	AL2O3+SIO2+ZrO2	-	-	-	99	99
  	ZrO2	-	-	-	5-7	15-17
  	Fe2O3	≤1.0	≤0.2	≤0.2	≤0.2	≤0.2
  	Na2O+K2O	≤0.5	≤0.2	≤0.2	≤0.2	≤0.2

   .
• Chemical properties of Ceramic fiber blanket:
•

• Chemical Content	Common Grade	Standard Grade	High pure Grade	High alumina Grade	Zirconium Grade
  AL2O3	44%	46%	47-49%	52-55%	39-40%
  AL2O3+SiO2	96%	97%	99%	99%	82-84%
  ZrO2	-	-	-	-	15-17%
  AL2O3+SiO2+ZrO2	-	-	-	-	99%
  Fe2O3	≤1.2	≤1.0	≤0.2	≤0.2	≤0.2
  Na2O+K2O	≤0.5	≤0.5	≤0.2	≤0.2	≤0.2



• Ceramic fiber blanket application:

• 1.)Industrial furnace,Heat treatment,High temperature pipe
• 2.)Insulating materials of boiler, turbine and nuclear power

  3.)Insulating material for face and top of industrial furnaces and heating device
• 4.)Excellent sound insulation for Construction Fire protection

  5.)High temperature filter material for nonferrous metal.
