Home > Products > Molybdenum Disilicide(MoSi2) heating elements > Molybdenum disilicide heating element
Molybdenum disilicide heating element
- 3000 Piece / Pieces per Month
- Zhengzhou Tianjin
- T/T Credit Card
You May Like
Product Details
| Brand Name | Kejia | Model Number | KJ best selling super molybdenum disilicide heating element | |
| Place of Origin | Henan, China |
Product Description
Specifications
1. MoSi2 heating element,2. Diameter, 3/6 - 12/24mm.
fessional maker
4. good service & early delivery
Model: U shape Molybdenum Disilicide Heating element
Features:
1. used in the high temperature under oxidizing atmosphere,
2. It will form the SiO2 film which can keep the element from being melted.
3. It has unique effect for resisting oxidization in the high temperature.
4. "U", "W" and "U-right angle” shapes heating elements are available.
Descriptions
Material Grade: M1700/M1800
d: Hot Zone Diameter
c: Cold Zone Diameter
Le: Hot Zone Length
Lu: Cold Zone Length
a: Shank Spacing
Order Sample
U Shape, Material Grade: M1700,
d-4mm, c-9mm, Le-450mm, Lu-450mm, a-25mm
Specify As: KJ-MoSi2-U, 4/9×450×450×25
Specification
| 1700°C Grade | 1800°C Grade | ||||||||
d/c (mm) | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 |
Le Max,mm | 350 | 450 | 1400 | 1400 | 1700 | 350 | 450 | 1400 | 1400 | 1700 |
Lu Max,mm | 300 | 450 | 1000 | 1000 | 1000 | 300 | 450 | 1000 | 1000 | 1000 |
a (mm) | 25 | 25 | 40/50 | 60 | 80 | 25 | 25 | 40/50 | 60 | 80 |
f (mm) | 25 | 25 | 45 | 75 | 100 | 25 | 25 | 45 | 75 | 100 |
g (mm) | 15 | 15 | 25 | 30 | 40 | 15 | 15 | 25 | 30 | 40 |
Nonstandard shape & size could be made according to your requirement. | ||||||||||
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: T/T, West union, etc.
Shipping and Delivery: by air/sea, in 10 days after receiving the payment
