WS-N220 Online Weight Checking and Sorting Equipment
- Shanghai
- T/T
You May Like
-
Check Weigher WS-N320 Online Weight Checking and Sorting
-
Check Weigher WS-N450 Online Weight Checking and Sorting for big size packing
-
Check Weigher WS-N500 Online Weight Checking and Sorting for big size packing
-
WS-N158 (5-600g) Full-automatic online weight checker for carton
-
Check Weigher WS-N500 Online Weight Checking and Sorting for big size packing
-
Check Weigher WS-N320 Online Weight Checking and Sorting Solution
Product Details
| Place of Origin | Shanghai, China | Brand Name | YuanxuPack | |
| Model Number | WS-N220 | Type | Checkweigher | |
| Power Supply | 220/380V | Display Type | Weinview | |
| Rated Load | 1kg | Accuracy | g |
Product Description
Specifications
High speed, SUS202rejector optional
Check Weigher WS-N220
Online Weight Checking and Sorting
FEATURE
1. Strong stainless steel structure; Water proof design(Optional).
2. High accurate load cell; Based on advanced DSP technology.
3. Automatic weighing compensation and zero tracking.
4. 200 products preset; Easy to edit and recall.
5. Quickly product shift and speed recall.
6. Quick USB data copy and restore system.
7. Color LCD touch screen with multi-language panel, easy to operation.
APPLICATION
Online foods package weighing and sorting.
Applied to packing foods quality control.
Used to check unit product’s weight whether meet target object, and automatically
reject sub-standard products.
SPECIFICATION
Type | WS-N220 |
Weighing Range | 10g-1kg |
Conveying Speed | 40-90m/min(adjustable) |
Speed(bags/min) | 90-130 |
Accuracy | ±0.3g - ±1.0g |
Belt Width | 220mm |
Weighing Method | Weighing Sensor |
Operational Method | Color LCD Touch Screen(Multilingual) |
Alarm | Buzzer, Lamp |
Rejection | Air Jet Type/ Flapper Type/ Pusher Type |
Products Preset | 200kinds |
Power Supply | AC110V/220V 50-60HZ |
Rated Output | 120W |
Air Supply | 0.6-1Mpa |
Air Pressure Connection Point (Optional) | 8mm(Optional) |
USB Copy System | USB data copy in EXCEL edition |
Weight | Appr.97Kg |
Conveyor Height | 750±50mm(Can be optional based on requirement) |
Dimension | 1500mm(L)*650mm(W)*1350±50mm(H) |
Above is standard data, different products size and working environment may effect above data.
