YK1650F-B economical pallet wrapping machine
- 1000 Set / Sets per Month
- shanghai
You May Like
Product Details
| Condition | New | Application | Apparel | |
| Packaging Type | Cans | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 1.12KW | Place of Origin | Shanghai, China | |
| Brand Name | yuanxu | Model Number | YK1650F-B |
Product Description
Specifications
prestretch film carriage, PLC control system, with self-induction, layers and speed adjustable.
PALLET WRAPPER
WORKING CAPABILITY IS 20-40 LOADS/HOUR
STRETCH FILM WRAPPING MACHINE
YK1650F-B STRETCH FILM WRAPPING MACHINE,PALLET WRAPPER
Technical Parameter
Turntable Diameter 1650 mm
Wrapping Height 1800mm
Turntable Height 85mm
Turntable Weight 2000 kg
Weight 600 kg
Power 1.35 kw
Voltage 220 V(single phase)
Wheel Speed 0~12rpm
Main Performance
Programmable Logic Controller, Optional winding program, Various parameters can be adjusted
Electric Switch automatically detects goods altitude
Pre-tension automatic film feeding institutions
Turntable slowly start, slowly breakup ,automatic reset
The top and bottom winding can be controlled alone
Auto , the hand operation can cut over , almost doesn,t need routine maintenance
Film System
Film frame is dynamic pre-tension institutions, Pre-tension can reach 250%,Reduce consumption of membrane quantity
Rise and fall speed of film frame is adjustable alone
Film feeding speed is adjustable ,separate DC motor control
Film system is dynamic institution ,a pull can run
Film frame is pure aluminum film frame ,light and stability
choose wear-resisting rubber roller ,long operating life
Up-down frame is simple chain structure ,stable and reliable
