VOLTAGE REGULATOR 1000 kva VOLTAGE REGULATOR

Specifications

VOLTAGE REGULATOR 1000 kva VOLTAGE REGULATOR PRICE

EPOXY CAST RESIN TRANSFORMER

VARIABLE VOLTAGE TRANSFORMER

DRY-TYPE CAST RESIN TRANSFORMER

POWER DISTRIBUTION TRANSFORMER

INDUSTRIAL AUTOMATIC VOLTAGE CONTROLLER

RECTIFIER TRANSFORMER

ISOLATION TRANSFORMER

POWER is an ISO 9001:2000, DUN BRADSTREET (862376458),   IEC, FGI, DIC, EEPC & NSIC registered company. Having five manufacturing plants in all over India. We are engaged in the manufacturing of Industrial Transformers up to  10 MVA (Epoxy Cast Resin Construction, Dry Type, Oil Cooled) low and medium voltage, Industrial Automatic Voltage Stabilizer ranging up to 7000 KVA capacity (U.K. based Brentford type), Variable voltage supply (0 – 33000 Volts), Special Purpose Transformers (step up / step down, auto transformers, Ultra Isolation Transformers), Rectifier equipments from 0-1500 Volts and up to 25,000 Amps. for Industrial applications.

 voltage regulator, which primarily consists of the following features :

• Linear, plus / minus type vertical rolling contact voltage regulator
  For making these regulators, we use heavy section of electrolytic grade rectangular copper strip instead of copper wire in order to minimize the losses & increase the efficiency of equipment. We also employ self lubricating Carbon Roller Assemblies instead of ordinary Carbon Brushes that offers more reliability and trouble free performance of the equipment.
• Double wound buck / boost type series transformer
  In our Buck / Boost transformer, we make use of CRGO lamination to reduce iron losses. The coils of Buck / Boost transformer are wound with heavy section of multi strips electrolytic copper to minimize copper losses to get better efficiency of the equipment.
• Electronic control circuit and meter panel
  Automatic Voltage Controller usually consists of very simple electronic control voltage circuit for monitoring and controlling voltage, repair and maintenance of which is very easy. The regulator and Buck / Boost transformer are oil cooled, placed in same or separate sheet steel tanks. These devices are provided with radiators for effective cooling. The coils of voltage regulators & Buck / Boost Transformers are vacuum impregnated and oven dried as per IS.
