Home > Products > Sand Washing machine > 2014 High Capacity New Screw Kinetic Sand Washer
2014 High Capacity New Screw Kinetic Sand Washer
- Qingdao
- T/T
You May Like
-
2014 High Capacity New Spiral Kinetic Sand Washer for Sale
-
New Double Spiral LX Sand Washer On Sale
-
Wheel Type High Quality Sand Washer Machine For Sand Production Line
-
Reliable Quality LX Series Spiral Sand Washer Price
-
China XS Series Wheel Sand Washer Supplier
-
Best Popular Screw Sand Washer Machine Manufacturer
Product Details
| Condition | New | Motor Type | AC Motor | |
| Power(W) | 11kw | Capacity(t/h) | 100 | |
| Place of Origin | Henan, China | Brand Name | zoonye | |
| Model Number | XL915 | Dimension(L*W*H) | 8500*2810*3600 | |
| Weight | 6.27t | Certification | CE, ISO9001:2000 | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Sand washer1.High degree cleaning-up
2.Reasonable structure
3.Large capacity
4.Low power consumption
High capacity new screw kinetic sand washer
Vibration new sand washing machine is mainly used for sand processing, electric pole factory, building work site and concrete dam, various sands classifying and dewatering. This machine has three functions: washing, dewatering, classifying.
Features
1.High degree cleaning-up
2.Reasonable structure
3.Large capacity
4.Low power consumption
Working Principle
The screw washer adopts inclination of 15°,under the water tub, three weir plates form the sediment pool, the screw head is immersed in this pool, the screw is driven by electric motor through reducer rotating continuously, the fresh water is feeding from porous plate at bottom of sediment pool.
Specification
Model | XL508 | XL610 | XL762 | XL915 | 2XL915 | XL1115 | 2XL1115 |
Screw Diameter(mm) | 508 | 610 | 762 | 915 | 915 | 1115 | 1115 |
Length of Tub (mm) | 6705 | 7225 | 7620 | 7585 | 7585 | 9782 | 9782 |
Max Feed Size (mm) | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 |
Capacity (t/h) | 20 | 40-50 | 50-75 | 100 | 200 | 175 | 350 |
Speed Of Screw (r/min) | 38 | 32 | 26 | 21 | 21 | 17 | 17 |
Motor Power (kw) | 5.5 | 7.5 | 11 | 11 | 2×11 | 15 | 2×15 |
Water Consumption (t/h) | 6-60 | 6-63 | 9-63 | 10-80 | 20-160 | 20-150 | 40-300 |
Overall Dimensions(L×W×H)(mm) | 8000×2343 | 8000×2050 | 8545×2650 | 8500×2810 | 8420×3765 | 10970×3945 | 10970×5250 |
Weight (t) | 2.67 | 3.80 | 5.23 | 6.27 | 11.11 | 10.18 | 17.94 |
Package & shipment
- Packaging: Standard Container, Nude Packs or in Bulk.
- Shipping:we deliver the cargo to China's main sea ports,such as Qingdao,Tianjin,Shanghai etc.And then the container will be transported to your country by sea.
Our Service
1.more than 12 months' warranty period
2.Erection and Commissioning
3.Operator Training
4.Spare Parts Supply
High capacity XL screw sand washing machine
