Product Details
| Condition | New | Type | Core Drilling Rig | |
| Power Type | Electric | Place of Origin | Henan, China | |
| Brand Name | Zoonyee | Model Number | HZ-200 | |
| Usage | Water Well | Voltage | 220v | |
| Power(W) | 15kw | Dimension(L*W*H) | 2.5*0.9*1.3m | |
| Weight | 1t | Certification | CE | |
| Warranty | 15 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
rock drilling rig*CE certificated
*in stock
*good quality
*fast delivery
Hight Quality Mini Core Drilling Rig For Sale
1. APPLICATIONS:
Geological drilling for railroad, highway, bridge tunnel, foundations of power station, Civil and industrial buildings, also drilling anchoring hole and blasting hole etc.
2. FEATURES
Spindle type mechanical transmission, hydraulic feed.
Hydraulic retracting lets drill body away from the drilling hole.
Hydraulic chuck, hand-powered chuck and hand-powered cylinder chuck, they are exchangeable.
Friction hoist, percussion drilling, easy to pull and push casing if equipped with vibrator.
Advanced design, reasonable arrangement, compact structure, beautiful looking.
Light weight, good detachability, easy to operate.
Equipped with special 6mA type derrick for user ordering.
3.Specifications | ||
Unity machine parameter | ||
Drilling depth | 30--200m | |
End hole caliber | 500-75mm | |
Drill rod caliber | 50mm | |
Drilling angle | 90°~75° | |
Drill weight (No include power) | 910kg | |
Unity machine dimensions | 2.5×1×1.3 2.5×0.9×1.3m | |
Spindle | ||
spindle speed | 64,128,287,557r/min | |
Spindle stroke | 450mm | |
Hoist | ||
Max.single line hoisting capacity | 2500kg | |
Single line lifting speed | 17,35,75,151r/min | |
Tightrope caliber | 12.5mm | |
Tightrope cubic measure | 35m | |
Hug floodgate caliber | 254mm | |
Hug folldgate belt width | 70mm | |
Distance between drill and hole | 400mm | |
Mud pump - Specifications | ||
Type | Horizontal single urn twin-action | |
Displacement | 170L/min | |
Diesle engine | S1115 model 22HP | |
Electric motor | Y160M—4 15kw 1440r/min | |
Maximum pressure | 1.5Mpa | |
Work pressure | 0.7Mpa | |
Water inlet caliber | 40mm | |
Water to exit caliber | 30mm | |
Triangle conveyer belt | B1728mm | |
