Product Details
Light Source | LED | Input Voltage(V) | DC12V | |
Lamp Power(W) | 96 | Lamp Luminous Flux(lm) | 8400 | |
Lamp Luminous Efficiency(lm/w) | 87 | Working Temperature(℃) | -20, 50 | |
Working Lifetime(Hour) | 20000 | IP Rating | IP33 | |
Certification | CE | Emitting Color | White | |
Lamp Body Material | Aluminum | Place of Origin | Fujian, China | |
Brand Name | SLT | Model Number | SL-BM011-960 |
Product Description
LED backlight LED Ladder Module for signage
Super bright double side led strip light 12V is applied to very big light box in shopping malls,hotels, clubs and other commercial establishments, as well as airports, railway stations and other public places,and even home places.
There are three different size with single side and double sides for your choice as below:
Item | SL-BM010-960 | SL-BM011-960 | SL-BM012-480 | SL-BM015-960 |
Desc. | single side 2835 | double side 2835 | single side 2835 | double side 2835 |
Voltage | DC12V | DC12V | DC12V | DC12V |
Watts | 2.4w/pc, 96w/sqm | 4.8w/pc, 192w/sqm | 1.2w/pc, 96w/sqm | 2.4w/pc, 192w/sqm |
Lumen | 210 lm/pc | 420 lm/pc | 105 lm/pc | 210 lm/pc |
C.T | 10000-14000K | 10000-14000K | 10000-14000K | 10000-14000K |
Angle | 120° | 120° | 120° | 120° |
Strip size | 500*10*2.5mm | 500*10*2.5mm | 250*10*2.5mm | 250*10*2.5mm |
Roll size | 500*2000mm (40pcs/roll) | 500*1000mm (20pcs/roll) | 250*2000mm (40pcs/roll) | 500*2000mm (40pcs/roll) |
Advantage:
1.Non-mechanical compression on the folding work light board and its components,
2.To prevent lamp beams don’t work, pls Protect the folding work light board during installation,
3.Meet the requirements and safety standards of electronic components before installing folding work light board (in the case of live work), to prevent short circuits pls don’t live operation,
4. Directly input 12V power
Double sided led strip light 12V package:
CAUTION:
*.Please read the specification first to make sure the using condition is fit.
*.Please shut off the switch before connect the product, then turn on.
*.Indoor use only.
Why clients choose us?
1. Good quality
2. Cheap price
3. Safety packaging
4. Short lead time
5. One-Stop service
Model | SL-BM011-960 |
LED | 3528 |
Power | 4.8W/strip |
Voltage | DC12±0.5V |
Lumen | 420LM |
CCT | 10000-14000K |
Angle | 120° |
Size | 500*10*2.5mm |
Quality control:
1. Before producing, we would strictly check the material, color, wick,etc.
2. Aging for every light about 12-24 hours
3. Our salesman would trace every phase of production from the beginning.
4. We have a QC team, every piece product sould be inspected before packing.
