ETL Listed High Power Competitive Price CE Cetificated 300 Led Panel LED Trade Show Light,dimmable for Exhibition Company

ETL listed High power Competitive price CE Cetificated 300 led panel LED Trade show light,dimmable led tile,led module supplier for exhibition

1. ETL listed  High power CE Cetificated LED Trade show lightexhibition company Specification for

ETL listed  High power CE Cetificated LED Trade show light Details for showcase

(1)ETL listed  High power CE Cetificated LED Trade show light Standard Accessories for showcase flat head screw:8PCS

Screw:4PCS

E-connector:4PCS

Insulation pad:4PCS

(2) ETL listed High power CE Cetificated LED Trade show light Optional Accessories for Aluminum profile IR CONTROLLER

 ETL listed High power CE Cetificated LED Trade show light Adaptor for showcase :

 ETL listed High power CE Cetificated  LED Trade show light Connection without dimmer for showcase :

 ETL listed High power LED Trade show light Installation for exhibition :

1.Non-mechanical extrusion on the LED light board and its components,

2. Protect the PCB light board during installation.

3.,Meet the requirements and safety standards of electronic components before installing LED light board (in the case of live work), don’t live operation, prevent short circuits.

4. It can be directly input DC/AC24V power. If it is installed with dimming remote, entering a remote control input terminal of the power supply output DC24V, again from the remote control output terminal connected to the circuit board, as shown above single dimming connection, and then its dimmable function works.

5. When install a large area, the PCB board should be put in the same direction, so that the PCB board positive +to positive +, negative -to negative -. After fixing with screw lock E-type gaskets connection, maximum connection 10 pcs with one power.

6. Each piece of the input voltage is DC24V, the input voltage can not be used directly with AC220V. 30x30cm per sheet lamp, the board power is 8W, Noted that the input voltage DC24V + corresponding to the lamp panel +, the input voltage of the the DC24V-corresponding lamp panel - , not allowed reversed connection.

7. Maximum power supply. 150W 24V switching power can supply up to 18pcs 30X30CM light board (8W).

4.ETL listed High power CE Cetificated LED Trade show light Features  for showcase

 ETL listed High power CE Cetificated Specification of each Adjustable LED Trade show light chip for exhibition :

5. ETL listed High power CE Cetificated Adjustable LED Trade show light Use manual for exhibition company

Please read the specification first to make sure the using condition is fit.

Please shut off the switch before connecting the product.

OUTPUT:DC24V/AC24V

Indoor use only.

Competitive price LED backlight Package for Aluminum profile :

High power

 ETL listed High power CE Cetificated LED Trade show light Application for exhibition :
