Home > Products > LED Power Supply > MW 30W ELN-30 Led Single Output Switching Power Supply
MW 30W ELN-30 Led Single Output Switching Power Supply
Negotiable
/ Piece
1 Piece(Min. Order)
- sz
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | MW | |
| Model Number | ELN- 3 0 | Output Power | Other, 1-30W | |
| Output Type | Single | Input Voltage | Other, AC90-260V | |
| Output Voltage | 5-48V | Output Frequency | 30W | |
| Output Current | 0.63-5A |
Product Description
Specifications
MW 30W ELN-30 led Single Output Switching Power Supply1. UL listed
2. High efficiency 92%
3. 2 years warranty
MW 30W ELN-30 led Single Output Switching Power Supply
Features :
1.Universal AC input / Full range
2.Protections: Short circuit / Overload / Over voltage
3.Cooling by free air convection
4.Built-in constant current limiting circuit with adjustable OCP level
5.Optional dimming function : 1.1~10VDC (D type) or PWM (P type) controlled
6.Fully isolated plastic case with IP64 level
7.Pass LPS
8.Suitable for LED lighting and moving sign applications (Note.8)
9.100% full load burn-in test
10.Low cost
11.2 years warranty
12.Class power unit, no FG
