compound graphite spiral wound gasket with SS304/316 inner or outer
- XINGANG PORT CHINA
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | HIG-01 | |
| Material | Metal | Shape | Ring Gasket | |
| Standard or Nonstandard | Standard |
Product Description
Specification:
1.Products are manufactured in accordance with all relevant gasket standards to suit flange designations: ASME B 16.20, ASME B 16.5, BS1560, ASME B 16.47 A (B), BS EN 1092, DIN, JIS, and NF, etc.
2.Color cord as ASME B 16.20 on request.
Product Standards:
TYPE OF SPIRAL WOUND GASKET:
spiral wound gasekest,have 4 types:
SW - Basic Type
Basic construction type without solid outer and inner ring is reinforced with several plies of metal with
filler to give greater stability and better compression characteristics. - Suitable for tongue and groove, male
and female or grooved to flat face flange assemblies.
SWI - Inner Ring Type
Solid inner metal ring acts as a compression stopper. To prevent accumulation of solids, reduce
turbulent flow of process fluids and minimize erosion. The gasket is between flange bore and the inside
diameter.The annular space is filled up by solid inner metal ring. - Suitable for male and female pipe flanges .
SWC - Outer Ring Type
Solid outer ring accurately locates the gasket on the flange face to give the additional radial strength to
prevent the gasket blowout and acts as a compression limiter. In case of installing the outer ring, it is very easy
to install the gasket to flange face because the end of outer ring will touch at bolts - Suitable for use with flat
face and raised face flanges.
SWCI - Inner & Outer Rings Type
An inner ring and outer ring type gasket will give an additional compression limiting stopper for gasket inner
and outer side. It will prevent the corrosion on flange face at annular space. - Suitable for use with flat face
and raised face flanges and specified for high pressure/temperature service - Class 900LB and above or where
corrosive or toxic media are present.
Structure :
2.Filler: this part is the main body of the gasket and different material is used in different conditions
3.Centering ring:the centering ring does not come into direct contact with contained fluid. It is normally made of carbon steel and electro plate or painted to avoid corrosion. Other materials are available on request.
4.Inner ring:inner ring is used to avoid excessive compression due to high seating stress in high pressure service and it is also used to reduce turbulence in the flange area. It is normally made of the same material as the gasket metallic strip.
Standard
ASME B 16.20, ASME B16.21 etc
Material
Carbon Steel, Stainless Steel, PTFE, Asbestos etc
Size
15mm to 6000mm (it depends on the type of the gasket and other factors)
Type
Spiral wound metal gasket with asbestos filler, Spiral wound metal gasket with graphite filler
PTFE impregnated asbestos gasket, PTFE envelopen gasket, PTFE gasket
Compressed asbestos class gasket, Flexible Graphite Composite Gasket, Non graphited Compressed white asbestos gasket, Expanded graphite cut gasket
Oval ring joint gasket, Octagonal ring joint gasket
Serrated gasket , Corrugated gasket, Oval graphite cut gasket, Metal jacketed gasket
VCS gasket, Insulating gasket kits
Advantages:
1. We are ODM&OEM, design according to your drawing.
2. Rich experience and good technology support( have engineers with more than 20 years experience).
3. Manufacturer and Trade Company.
4. Low MOQ is accepted.
5. 100% inspection before delivery.
6. Competitive price with high quality.
7. Convenient transportation ( Shenzhen).
