ss316 metal spiral wound gasket manufacturer
- XINGANG PORT CHINA
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | HIG-01 | |
| Model Number | Seals Gasket | Material | Metal | |
| Shape | Ring Gasket | Standard or Nonstandard | Standard |
Product Description
Specification:
1.Products are manufactured in accordance with all relevant gasket standards to suit flange designations: ASME B 16.20, ASME B 16.5, BS1560, ASME B 16.47 A (B), BS EN 1092, DIN, JIS, and NF, etc.
2.Color cord as ASME B 16.20 on request.
Product Standards:
TYPE OF SPIRAL WOUND GASKET:
spiral wound gasekest,have 4 types:
SW - Basic Type
SWI - Inner Ring Type
SWC - Outer Ring Type
SWCI - Inner & Outer Rings Type
Structure :
2.Filler: this part is the main body of the gasket and different material is used in different conditions
3.Centering ring:the centering ring does not come into direct contact with contained fluid. It is normally made of carbon steel and electro plate or painted to avoid corrosion. Other materials are available on request.
4.Inner ring:inner ring is used to avoid excessive compression due to high seating stress in high pressure service and it is also used to reduce turbulence in the flange area. It is normally made of the same material as the gasket metallic strip.
Material:
| Materials of Steel | Fillers | General Thickness (mm) | ||||
| Name | Code | Name | Code | Applicable Temperature℃ | V-shaped Gasket/Ring | W-shaped Gasket/Ring |
| Carbon Steel | CS | Asbestos | ASB | 500 | 3.2/2.0 4.5/3.0 5.5/3.0 | 4.8/3.0 7.2/4.0 |
| Stainless Steel | 304(L),316(L) | Graphite | FG | 650 | ||
| Monel | Mon | Teflon | PTEF | 260 | ||
| Nickel, Titanium | Ni, Ti | Mica | MICA | 850 | ||
| Inconel | Inc | Ceramics | CER | 1300 | ||
| Hastelloy Alloy | HAST | Non Asbestos | NAF | 500 | ||
