Hot Oil Coal Fired Boiler
- Qingdao China
- T/T
You May Like
Product Details
| Condition | New | Type | Natural Circulation | |
| Usage | Industrial | Structure | Other, Pipe Coil | |
| Pressure | Low Pressure | Style | Horizontal | |
| Fuel | Other, Coal-fired, AII,AIII | Place of Origin | China | |
| Brand Name | Xingfu Boiler | Model Number | YLW Series Coal Fired Boiler | |
| Output | Other, Hot Oil | Dimension(L*W*H) | Depend on Boiler Type | |
| Weight | 17--35T | Certification | SGS,ISO14001,CE and ASME | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Thermal Oil Coal Fired Boiler
This series boiler is a new type of special boiler with low-pressure ,high-temperature,The heating temperature can reach liquid 340°c or steam 400°c, if you craft need to be heated stable and do not allow to use flame directly,it can reach 150°c--380°c and used in a variety of production situations,The furnace use generally coal,oil and gas as fuel,and this series boiler takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make Liquid circulation;then the thermal energy will transmitted to the devices and back to the furnace to be the devices and back to the furnace at low pressyre,and make liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated,So the boiler can get high working temperature at low pressure,and make a better usage of heat,it is a kind of safe boiler with high efficiency and low power consumption
Uses:
1, Chemical industry-polymerization industry,oil industry,reaction tank,distillation,enrichment;
2, Plastic industry-plastic and squeeze to finalize the design;
3, Textile industry- resin stenters,dyeing machine and the dry room,high temperature machine,roller;
4, Rubber industry-cooking,dry,vegetable oil refining
5, Wood industry-heating to finalize the design of chipboard,sandwich plate,wamu board,fiber;
6, Paper industry-multi-layer cardboard of packed carton box,dying and desiccation
7, Others-heating of metal electroplating slot,coating condensation,drying,distillation of pharmaceutical industry,reduction,concentration,dehydration,air conditioning industry,etc
Type
Item | YLW-- 1400 MA | YLW-- 1800 MA | YLW-- 2500 MA | YLW-- 3000 MA | YLW-- 3500 MA | YLW-- 4200 MA | YLW-- 5600 MA | YLW-- 7000 MA | YLW-- 8200 MA | YLW-- 9300 MA | |
Rated Thermal Power | Kw
| 1400 | 1800 | 2500 | 3000 | 3500 | 4200 | 5600 | 7000 | 8200 | 9300 |
Rated Pressure | Mpa | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.01 |
Rated Outlet Temperature | ℃ | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
Rated Inlet Temperature | ℃ | 290 | 290 | 290 | 290 | 290 | 290 | 290 | 290 | 290 | 290 |
Designed Thermal Efficiency | % | 73 | 73 | 73 | 73 | 73 | 73 | 73 | 73 | 73.5 | 76.7 |
Heating Area | M² | 130 | 157 | 168.7 | 192.2 | 263.8 | 298 | 490.3 | 574.5 | 634.2 | 723.4 |
Heat Medium | Conduction Oil | ||||||||||
Fuel | AII,AIII | ||||||||||
Fuel Consumption | Kg/h | 290 | 496 | 620 | 797 | 895 | 996 | 1248 | 1495 | 1744 | 1993 |
Oil Capacity | M³ | 2.47 | 2.73 | 2.96 | 3.17 | 3.24 | 3.46 | 5.38 | 6.30 | 8.03 | 9.31 |
Oil Circulation | M³/h | 120 | 130 | 143.3 | 172 | 187 | 200 | 233.5 | 272.4 | 403.7 | 457.8 |
Total Installed Capacity | Kw | 79.9 | 87.65 | 87.65 | 104.65 | 104.65 | 104.65 | 144.1 | 144.1 | 201.2 | 287.5 |
Tubing Diameter | DN | 150 | 150 | 150 | 150 | 150 | 150 | 200 | 200 | 300 | 300 |
Maximum Transportation Weight | Kg | 17450 | 18650 | 19579 | 20492 | 22730 | 24660 | 26149 | 28309 | 32425 | 34782 |
Dimension | (Mm)L W H
| 4960 2519 2656 | 4960 2519 3280 | 5207 2519 3388 | 5207 2519 4100 | 6432 2700 4365 | 6432 2700 4810 | 7866 3513 3314 | 7866 3513 3500 | 8086 3460 3671 | 9669 3460 3671 |
