DZL Coal Steam Boiler
- Qingdao China
- T/T
You May Like
Product Details
| Condition | New | Type | Natural Circulation | |
| Usage | Industrial | Structure | Other, Fire Tube, Single drum,chain grate | |
| Pressure | Low Pressure | Style | Horizontal | |
| Fuel | Coal-fired | Place of Origin | Shandong, China | |
| Brand Name | Xingfu | Model Number | DZL | |
| Output | Steam | Certification | ASME ISO SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
DZL coal steam boiler
DZL coal steam boiler
1.The boiler shall employ single return screwed pipe,arched tube plate,and aerofoil flue,which shall make quasi-steel resistance of the shell to change into quasi-steel,avoiding tube plate crack due to high temp.
2.The rational design of cycle scrap,shall prevent the bottom of the shell from being heated & swelling.Water circulation reliabilities shall be improved by installing supply water injectors,avoiding the ash deposition of water-wall tube.So the reliablie combusion equipment shall ensure the normal operation of the boiler.
3.The optimization of boiler type shall decrease the size of boiler body,reducing the cost of boiler house 30%.
4.Because of excellent combustion efficiency,automatic coal supply,automatic slag-removal,the labor intensity of the stoker shall be reduced.
Model/Parameter/Item | DZL 2-0.7-AII | DZL 2-1.25-AII | DZL 4-1.25-AII | DZL 4-1.6-AII | DZL 6-1.25-AII | ||
Rated capacity | t/h | 2 | 2 | 4 | 4 | 6 | |
Operation pressure | Mpa | 0.7 | 1.25 | 1.25 | 1.6 | 1.25 | |
Steam temperature | C | 169.6 | 194 | 194 | 203 | 194 | |
Water-inlet temperature | C | 20 | 20 | 20 | 60 | 20 | |
Heating efficiency | % | 77.4 | 77.4 | 81 | 81 | 77.4 | |
Area of stoker | m2 | 3.04 | 3.2 | 5.4 | 5.4 | 7.48 | |
Steam valve diameter | mm | PN1.6 DN80 | PN1.6 DN80 | PN1.6 DN100 | PN2.5 DN100 | PN1.6 DN125 | |
Water inflow valve diameter | mm | PN1.6 DN40 | PN1.6 DN40 | PN1.6 DN50 | PN2.5 DN50 | PN1.6 DN50 | |
Fuel | Coal available |
| II type bitumite,lcv:17700-21000KJ/kg | ||||
Consumption | kg/h | 290 | 290 | 580 | 580 | 960 | |
Dimension of biggest parts for shipment (LxWxH) | m | 5.82*2.1*3.22 | 5.82*2.1*3.22 | 6.5*2.66*3.52 | 6.5*2.66*3.52 | 7.1*3*3.65 | |
Weight of biggest parts for shipment | t | 18 | 19 | 27 | 29 | 32 | |
Overall dimension of Assembled boiler (LxWxH) | m | 6.5*4.0*3.7 | 6.5*4.0*3.7 | 7.2*4.5*4.0 | 7.2*4.5*4.0 | 7.9*4.5*4.1 | |
Water supply | Model |
| 11/2GC-5*4 | 1 1/2GC-5*4 | 11/2GC-5*7 | 1 1/2GC-5*7 | 2GC-5*6 |
Motor power | kw | 3 | 7.5 | 7.5 | 11 | 15 | |
Blast fan | Model |
| G6-41-13No 5.4A | G6-41-13No 5.4A | G6-41-13No 6.4A | G6-41-13No 6.4A | G6-41-13No 7.1A |
Flow | m3/h | 4358-2310 | 4358-2310 | 7358-3596 | 7358-3596 | 10354-5349 | |
Pressure | Pa | 994-1254 | 994-1254 | 1436-1181 | 1436-1181 | 2270-1697 | |
Motor power | kw | 3 | 3 | 5.5 | 5.5 | 7.5 | |
ID fan | Model |
| Y6-41-13No 5.4C | Y6-41-13No 5.4C | Y6-41-13No 7.1C | Y6-41-13No 7.1C | Y6-41-13No 10C |
Flow | m3/h | 8901-4350 | 8901-4350 | 15219-8171 | 15219-8171 | 32144-16607 | |
Pressure | Pa | 2568-3240 | 2568-3240 | 2454-3283 | 2454-3283 | 2574-3444 | |
Motor power | kw | 11 | 11 | 22 | 22 | 37 | |
