Plastic Waterproof 6 Pin Connector
- Shenzhen
- L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SZCNT | |
| Model Number | CNT02-PF/PH | Type | Other | |
| Application | Power | Gender | Other, plug and socket |
Product Description
Specifications
plastic waterproof 6 pin connector1.keying notches 0/40/60/80/170/205
2.pin position:2/4/5/6/7/8/9/10/14
3.stocks available
General Introduction
• CNT02 plastic waterproof 6 pin connector
• Plastic push-pull electrical connector
• Specification
1. working voltage: 0.35KV/AC, 0.5KV/DC
2. contact diameter: 0.7mm
3. soldered type diameter: 0.6mm
4. rated current: 6A
5. environmetal working temperature: -50~+125°c
6. mechanical endurance: at least 5000 times (continuously 1000 times)
• Certifications
TÜV, GS, UL, CE, ROHS, ISO9001, ISO14000
• Application
used for some industrial fields, such as communication, electronic and meidcal equipments.
• Characteristics
1. Push-pull button makes it easy to connect and separate.
2. An automatic lock make it reliable to be connected.
3. An all plastic shell makes it adaptable to environment.
4. Amodified design of key makes it to avoid misinserting.
5. Compact structure makes it small-size.
6. Various termination-solder cup, crimp or PCB type.
