Impact Resistance UHMW-PE Products Plastic Sheet Manufacturer
- Qingdao or Tianjin
- T/T
You May Like
-
UHMW-PE Products Lightweight Recycled Uhmw Plastic Sheet
-
Impact Resistance UHMW-PE Products Lightweight Plastic Sheet Black White Color
-
Impact Resistance UHMW-PE Products Plastic Sheet Holes
-
Impact Resistance UHMW-PE Products White Color 2mm Plastic Sheet
-
Plastic Colored Wear Resistant Uhmw pe Black Plastic Plate Manufacturer
-
Plastic Colored Wear Resistant Yellow Uhmw Sheet Sizes
Product Details
| Place of Origin | Henan, China | Brand Name | Sanyou | |
| Model Number | SY-UP04A108 | Material | Other, PE, PE | |
| Thickness | 6-200mm, 6-200mm | Size | 1000*3000mm, 1000*3000mm |
Product Description
Specifications
UHMWPE plastic sheet1.no water absorption
2.super wear resistant
3.self-lubricating
4.ISO9001
Impact Resistance UHMW-PE products plastic sheet manufacturer
1. Advantage
1.Abrasive resistance which always have in thermoelectricity polymer.
2.Best shock resistance even in low temperature.
3.Low frictional factor, and well sliding bearing material.
4.Lubricity( no caking, in adhesion) .
5.Best chemical corrosion resistance and stress craze resistance.
6.Excellent machinery process ability .
7.Lowest water absorption(<0.01%) .
8.Paragon electric insulativity and antistatic behavior .
9. Nice high energy radioactive resistance.
10.Density is lower than other thermoplastics (< 1g/m3).
11.Long using temperature range: -269°C--90°C.
2.Main characteristics:
The main performance comparison
High abrasion resistance
Materials | UHMWPE | PTFE | Nylon 6 | Steel A | Polyvinyl fluoride | Purple steel |
Wear Rate | 0.32 | 1.72 | 3.30 | 7.36 | 9.63 | 13.12 |
Good self-lubricating properties,low friction
Materials | UHMWPE -coal | Cast stone-coal | Embroidered plate-coal | Not embroidered plate-coal | Concrete coal |
Wear Rate | 0.15-0.25 | 0.30-0.45 | 0.45-0.58 | 0.30-0.40 | 0.60-0.70 |
High impact strength, good toughness
Materials | UHMWPE | Cast stone | PAE6 | POM | F4 | A3 | 45# |
Impact strength | 100-160 | 1.6-15 | 6-11 | 8.13 | 16 | 300-400 | 700 |
3.Sheet Size Available:
Dimensions: | Typical Thickness: |
3000mm*1000mm | 5mm-250mm |
3000mm*1500mm | |
2000mm*4000mm | |
4000mm*1200mm | |
1200mm*3000mm |
*If required,also available in thickness from 1mm-250mm.
4.Technical parameter
Subject | Unit | Paraters |
Tensile strength | Mpa | >30 |
Compression strength | Mpa | ≥41.8 |
Bending strength | Mpa | ≥32 |
Impact strength | KJ/m² | ≥140 |
Ball identation strength | N/mm² | ≥40.8 |
Surface resistivity | Ω | 4.9×10¹³ |
Water absorption | % | 0.0001 |
Relative waer rate | G/cm² | ≤0.09 |
Frication coefficent | % | <0.09 |
5.Main Products show
