Home > Products > Carbide plates > Carbide Gauge Block From Zhuzhou Jinggong
Carbide Gauge Block From Zhuzhou Jinggong
- Any port of China
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
Product Details
| Place of Origin | Hunan, China | Brand Name | ZZJG | |
| Model Number | CTA |
Product Description
Specifications
Carbide Gauge Block from Zhuzhou Jinggong:-ISO 9001 Registered
-100% raw material
-Good wear resistance
Carbide Gauge Block from Zhuzhou Jinggong:
Product Information:
*Carbide Gauge Block from Zhuzhou Jinggong
is suitable for the production of various types of electrical machine & electronic progressive dies and punches etc
Properties & Applications:
Carbide Gauge Block from Zhuzhou Jinggong's Material:
Grade  |   Density  | T.R.S  | Hardness  | Application  |
YG6X  | 14.95  | ≥1800  | ≥91.5  | For drawing steel and nonferrous wires or bars of less than D6.00mm under not so much stress.  |
YG6  | 14.95  | ≥1900  | ≥90.5  | For drawing steel, nonferrous alloy bars of less than D20.00mm under more stress and also for drawing tubes of less than D10.00mm.  |
YG8  | 14.8  | ≥2200  | ≥89.5  | For drawing steel and nonferrous bars and tubes, also for manufacturing mechanical parts, tools and wear parts.  |
YG10  | 14.5  | ≥2400  | ≥88.5  | |
YG15  | 14.00  | ≥2800  | ≥87.0  | For drawing steel bars and tubes with a high reduction rate and for manufacturing anvils, drilling and punching and impacting.  |
Product Display:
Carbide Gauge Block from Zhuzhou Jinggong:

Packng Details:
Regarding to the packing of Carbide Gauge Block from Zhuzhou Jinggong,
we often use:
Inner by bubble bag with sponge,Outter by Carton Box,or as request by customer
Company Brief Discription:
Founded in May 2001,with an area of 15418 square meters' factory,over 10 years OEM & ODM experience,so we have the confidence in:
1.We,JINGGONG,can accept order of all kind of special designed tungsten carbide products.
2.We,JINGGONG,promise you the 100% raw material.
3.We,JINGGONG,can finish your order within 7-30 days upon confirm the prepaid.
Also YOU and your drawing papers are warmly welcomed.

Quality Assurance:
we,JINGGONG,owned ISO 9001:2008 , ISO 14001:2004 certification:
Support:
Whether you are looking for the right tool or need help with one you already own, we,
ZHUZHOU JINGGONG CEMENTED CARBIDE CO.,LTD. are here to help:
Order Support Product Support
Contact:Ms.Ada Linn Contact:Mrs.He
Tel:0086-731-22896701 0086-731-22896708
Mob / What's APP: 0086-13055190722
Line / We chat ID: adalinn
Skype:ada_linn
Email:sale1 at
jgcarbide01 at
Add:Jinggong Industrial Park,Kunlunshanb Road,Tianyuan District,Zhuzhou,Hunan,China
