Automatic Paperboard/cardboard laminating machine with reversing system

Specifications

Automatic Paperboard/cardboard laminating machine with reversing system

G&Z group is one of leading manufacturers specialized in fully automatic laminating machines in China, our automatic laminating machines are suitable for the high speed and automatic lamination of color printed top sheet and corrugated paperboard, and have been installed all of the world, besides of the top machines' quality, we also have earned good reputation on our aftersales services.

Main technical parameter

Performance

   Top sheet feeder

a. Adopting high speed automatic feeder. Max. performance can reach 12000 time/hour.

b.With pneumatic side register, top paper can be transported to laminating unit more accurately.

c. Equipped with pre-loading system.

d.Side-loading can be optional.

   Bottom sheet feeder

a.Vacuum suction feeding. Imported high quality suction belt provides stabilized feeding performance.

b.Sheet range: Single face flute A, B, C, E,F and double face flute.

c.With Optional Servo driving system, max. feeding speed can reach 9000 sheet/hour.

    Gluing & Laminating unit

a.Chromed gluing roller can save glue consumption.

b.Automatic glue supplying according to glue level between rollers. Avoid glue overflow. Automatic warning for glue shortage

c.Elastic front register can avoid bottom sheet from exceeding. Positioning of top and bottom sheet can be optimized for high precise lamination.

    Compression unit

a.Adjustable floating compression unit. Durable high quality compression belt.

b. Compressing speed is variable with inverter for different paper and glue.

    Pile reversing System

a.Automatically reverse piles of paper and then deliver to down stacker without stop.

b.It can minimize the problem of paper curve after lamination, saving the labor cost for restacking.Rapidly improve the production quality and efficiency.

    Non-stop automatic down stacker

a. Non-stop paper delivery for continuous production without shut down of paper download.

b. Full automatic process with simple operation.

    Operation

a.Integrated touch screen control with friendly interface.

b.With its ease of use, operator can easily control the whole production process.

    Component

a.Critical driving parts only adopt NSK bearing.

b.High quality main electrical components like from Schneider, provide reliable system performance and ease of maintenance
