DVB-S to DVB T Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
- 2000 Piece / Pieces per Month
- chengdu
- Credit Card
You May Like
-
DVB-S2 to DVB T Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
-
COFDEM DVB T Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
-
DVB-S to DVBT Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
-
DVB-S2 to DVBT Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
-
COFDEM to DVBT Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
-
satellite to COFDEM Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
Product Details
| Place of Origin | Sichuan, China | Brand Name | sochuang | |
| Model Number | SC4126 |
Product Description
DVB-S to DVB T Modulator (8*DVB-S/S2 in,3*DVB-T RF out)
8*DVB-S/S2 to 3*DVB-T modulator
Overview
DVB-S2 to DVB-T Trans-modulator support 8*DVB-S/S2 (QPSK/8PSK) transponders input multiplex, and output selected programs through 3*DVB-T RF.
Technical Specification
Input | Frequency | 950~2150 MHz | |
Symbol Rate | 1~45 Msps | ||
RF Tuner in | 8*DVB-S/S2 Transponders/Tuners | ||
Output | RF | 3in1 DVB-T F-head | |
Frequency Range | 36~900MHz, 1KHz step | ||
Output Level | 60~90dB | ||
Constellation | QPSK, 16 QAM, 64 QAM | ||
Bandwidth | 6M, 7M, 8M | ||
Baudrate | 1/2, 2/3, 3/4, 5/6, 7/8 | ||
Transmode | 2K, 8K | ||
Protection Interval | 1/32, 1/16, 1/8, 1/4 | ||
MER | ≥40dB | ||
Level Attenuation Range | 0~30dB | ||
Control | Front panel | NMS (Ethernet Port), Keyboard + LCD(front panel) | |
General Features | Temperature | 0~45°C (Operation); -20~80°C (Storage) | |
Size | 482mm×410mm×44mm | ||
Power | 100-240VAC, 50Hz, 25W | ||
Order Guide
4126 | 8×DVB-S2 to DVB-T TransModulator(8*DVB-S/S2 in,3*DVB-T RF out) |
4208 | 8×AV in, DVB-T RF out |
4202 | 4IN1 H.264 HDMI DVB-T Modulator(4HDMI in,DVB-T RF out) |
4106 | DVB-T Modulator(ASI IN,DVB-T RF out) |
Network management software
Satellite input parameter setting:
satellite signal monitor:
programs multiplex setting:
DVB-T modulator output setting:
Nit table edit and insert:
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
