fill-seal pouch machine
- 0 per Month
- Shanghai/Nanjing
You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Usage | Other Forming Machine | Place of Origin | Jiangsu, China | |
| Brand Name | DALAI | Voltage | 280v | |
| Power(W) | 8kw | Dimension(L*W*H) | 5200x2000x1700mm | |
| Weight | 2500kg |
Product Description
Specifications
This machine is used to weld stand up spout pouch. It is suitable for packaging juice, jelly, milk ,liquid pets food .
1.Usage
This machine is used to weld stand up spout pouch. It is suitable for packaging juices, jelly, milk,Liquid pets food and Dish washing liquid.
2. Main Technique Features
l Spout fitting and sealing with self-standing pouches and penguin style pouches
l Servo motor drive
l PID temperature control
l Clear display and easy operation
l Plastic pouches lined in the special holding channel for later feeding
l Trouble alarm display and shooting
Spare and accessory parts:4 gear cases ,3 slicers, SMC, couplings.
3. MAIN TECHNICAL SPECIFCATIONS
Pouch pattern | Stand up Pouch, Three Side Seal Pouch, Center Seal Pouch, Side Gusset Pouch, Spout Pouch |
Color of machine | White |
Pouch size | Width (60~122)mm,Height(60~230)mm Special specifications can be tailor-made |
Control mode | PLC+Mechanical transmission |
Hot-sealing | Six groups (12pcs) |
Compressed air | 0.5Mpa. 10L/min |
Control system | PLC+Mechanical transmission |
Power | 380V 50HZ( Special specifications can be tailor-made ) |
Main motor power | 8Kw,Warm-up(20Kw) |
Efficiency | 1~80Pcs/min |
Accuracy | ±1mm |
Weight | 2500Kg |
Pouch mode | Single or double group |
Dimension of the machine | 5200x2000x1700mm |
4.ELECTRONIC CONTROL SYSTEM
TEMPERATURE SYSTEM | |
Temperature mode | PID mode |
Control accuracy | 1~2°C |
Heating system | Warm up and sealing |
Heating control | 0~300°C |
Protection system | Torque protector(2 groups,Italy) |
HOT SEALING SYSTEM
Drive mode | Mechanical transmission |
Sealing knife size | by the customer-specific |
Thickness | 5~15mm |
Material | Hard aluminum and copper |
Temperature control | Hand operation |
CONVEYER SYSTEM | |
Structure | Automatic |
Drive mode | Automatic |
ARRANGED SYSTEM | |
Drive mode | Pneumatic drive |
Control mode | Central control system |
Pouch testing | Vacuum testing |
