DVB-C 8IN1 MUX-Scrambler IP Modulator (64 IP Input to 8RF Out)
- Chengdu
- Credit Card
You May Like
-
SC-4144 ip Qam Modulator With Scrambler 8in1 / IP to DVB-C
-
IP Multiplexer Scrambler QAM Modulator 64 IP Input)/ ip to rf Modulator
-
4in1 DVB-T COFDM CI IPTV MULTICAST IRD (4 DVB-T/T2 RF In,4 ASI+IP/32*SPTS*multicast Out)
-
SC-5311 Full hd Decoder/hd Iptv Decoder/dvb-t/t2 Decoder
-
SC-4124 Gigabit Edge Modulator
-
SC-4124 16in1 ip Qam Modulator With Mux-scrambler
Product Details
| Place of Origin | China | Brand Name | Sochuang | |
| Model Number | SC-4144 |
Product Description
SC-4144 8IN1 IP QAM Modulator with MUX-Scrambler
Overview
SC-4144 8IN1 IP QAM Modulator with MUX-Scrambler supports 64×IP input and 8×RF output. The input IP signal can be sent to signal processor and be converted to TS (transport stream). It integrates multiplexer, scrambler and QAM/DVB-C modulator. It supports 4 CAS/SMS SimulCrypt. It suits 1U rack and can be configured by front panel LCD and NMS (network management software). Its high-integrated and cost-effective design makes it widely used in varieties of digital broadcasting distribution systems.
Features
uIntegrated mux-scrambler modulator
u64×IP input
u8DVB-C RF output
uSupport 4×CAS/SMS
u8M cache, anti-burst stream
u PID filter and re-mapping
u PSI/SI edit, NIT table inserts and PCR correction
u LCD/Keyboard control by front panel and network management by Ethernet
Technical Specifications
Input | IP | 1000mbps IP port (64×IP in) |
Output | Interface | 8×RF, F-head |
Impedance | 75Ω | |
Constellation | 16, 32, 64, 128, 256 QAM | |
Symbol Rate | 5~9 Msps, 1Ksps step | |
Error-Correcting Codes | RS code188/204 | |
MER | ≥40dB | |
BER | 0 | |
Output Level | 90~110dBuV | |
Level Test Port | 70~90dBuV | |
Level Attenuation Range | -20dBm~0dBm (per carrier), 0.5dB step | |
Frequency Range | 47MHz~870MHz | |
Multiplexer | from the input 64×IP | |
Scrambler | support 4×CAS/SMS; head-end implementation of DVB simulcrypt (ETSI TS 103 197 V1.4.1) | |
Management | network RJ-45, 10/100M | |
Keyboard+LCD | ||
General Features | Size | 482mm×280mm×44mm |
Temperature Range | 0~45°C (Operation); -20~80°C (Storage) | |
Power | 100-240VAC, 50Hz, 25W | |
Network Management
Modulator:
IP IN:
Multiplex:
Scrambler:
Edit NIT:
PID Passthrough
Edit PSI
l Free pre-sales and after-sales technical support
l 3 years warrantly
l Remote online support and training
l Hardware/Software upgrade support
